Water Pump Impeller Kit – Fits Suzuki DT20-40 2-Stroke & DF25-60 4-Stroke (Replaces 17400-92J00, 0778317)

$37.00

Shipping calculated at checkout.

Water Pump Impeller Kit – Fits Suzuki DT20-40 2-Stroke & DF25-60 4-Stroke (Replaces 17400-92J00, 0778317) is backordered and will ship as soon as it is back in stock.

Worry-free returns

You may return most new, unopened items within 7 days of delivery for a full refund. We'll also pay the return shipping costs if the return is a result of our error (you received an incorrect or defective item, etc.).

You should expect to receive your refund within four weeks of giving your package to the return shipper, however, in many cases you will receive a refund more quickly. This time period includes the transit time for us to receive your return from the shipper (5 to 10 business days), the time it takes us to process your return once we receive it (3 to 5 business days), and the time it takes your bank to process our refund request (5 to 10 business days).

If you need to return an item, simply login to your account, view the order using the "Complete Orders" link under the My Account menu and click the Return Item(s) button. We'll notify you via e-mail of your refund once we've received and processed the returned item.

Delivery and Shipping

Free standard shipping on all orders under 1 KG

If you have any questions, feel free to email us at info@sierramarines.com, and we’ll get back to you within 20–36 hours.

Product Details

This complete Water Pump Impeller Kit provides everything needed to service the lower unit water pump on a wide range of Suzuki and Johnson/Evinrude outboards. It fits Suzuki 2-stroke models from 20-40 HP (1986–2000) and 4-stroke models from 25-60 HP (1999–2010), plus specific earlier DF90-140 models. It also fits select Johnson/Evinrude 40-50 HP 4-stroke engines from 2000–2002.

This kit serves as a direct interchange for Suzuki part number 17400-92J00, Johnson/Evinrude 0778317, Sierra 18-3242, and other equivalent references listed in the matrix below.

Engineered for direct OEM-equivalent installation.
Features a durable 6-blade rubber impeller design.
Includes a full set of stainless steel hardware, gaskets, and housing.

Part Number Matrix

Use this matrix to confirm equivalent references across OEM and aftermarket.

Brand	Part Number
Suzuki	17400-92J00
Suzuki	17400-96354
Suzuki	17400-96403
Johnson/Evinrude	0778317
Johnson/Evinrude	5031415
Johnson/Evinrude	5031744
Johnson/Evinrude	5032166
Johnson/Evinrude	5034358
Sierra	18-3242

Engine & Model Compatibility

Confirm your engine model/year in the table below.

For Suzuki models, pay close attention to the model codes, years, and serial number ranges, especially for DF90-140 HP engines where fitment is limited to earlier production runs.

Brand	Model	Rated HP	Stroke	Years	OEM Part No.	Notes
Suzuki	DT20	20	2-Stroke	1986–2000	17400-96354
Suzuki	DT25	25	2-Stroke	1986–2000	17400-96354
Suzuki	DT30G-Y	30	2-Stroke	1986–2000	17400-96354
Suzuki	DT40C-W-G-X	40	2-Stroke	1986–1999	17400-96403
Suzuki	DT25C, DT30C-K-Y	25-30	2-Stroke	1989–2000	17400-96354
Suzuki	DF25, DF30	25-30	4-Stroke	2000–2007	17400-92J00
Suzuki	DF40, DF50	40-50	4-Stroke	1999–2010	17400-92J00
Suzuki	DF90	90	4-Stroke	S/N 680686 to 889999	17400-92J00	Earlier serial number models
Suzuki	DF100	100	4-Stroke	S/N 9813204 & Below	17400-92J00	Earlier serial number models
Suzuki	DF115T	115	4-Stroke	S/N 681518 to 983178	17400-92J00	Earlier serial number models
Suzuki	DF115Z	115	4-Stroke	S/N 880001 to 980055	17400-92J00	Earlier serial number models
Suzuki	DF140T	140	4-Stroke	S/N 682149 to 983645	17400-92J00	Earlier serial number models
Suzuki	DF140Z	140	4-Stroke	S/N 680234 to 980353	17400-92J00	Earlier serial number models

For Johnson/Evinrude models, this kit is compatible with specific 4-stroke units manufactured between 2000 and 2002.

Brand	Model	Rated HP	Stroke	Years	OEM Part No.
Johnson	E40/J40	40	4-Stroke	2000–2002	0778317/5031744
Johnson	E50/J50	50	4-Stroke	2000–2002	0778317/5031744
Evinrude	E40/J40	40	4-Stroke	2000–2002	0778317/5031744
Evinrude	E50/J50	50	4-Stroke	2000–2002	0778317/5031744

Technical Specs

Product Type: Water Pump Impeller Kit
Installation: Direct OEM replacement
Dimensions: Impeller: 67.5 mm diameter × 16.18 mm height (2.66 × 0.64 in)
Impeller Hub Diameter: 17.10 mm (0.67 in)
Other Technical Attributes: 6 blade rubber impeller design with stainless hardware

What’s in the Box

1 x Water Pump Impeller (17461-96312)
1 x Water Pump Housing
1 x Water Pump Base Plate/Panel
1 x Gasket Set
1 x Hardware Kit (screws, washers)

Installation Notes

Disconnect the negative battery cable for safety.
Place the outboard gear shift in the neutral position.
Remove the lower unit mounting bolts and carefully lower the gearcase.
Unbolt and remove the existing water pump housing to access the impeller.
Remove the old impeller, gaskets, and wear plate, noting their orientation.
Thoroughly clean the mating surfaces of any old gasket material or debris.
Install the new base plate gasket, wear plate, and impeller. Rotate the driveshaft clockwise to help seat the impeller blades.
Lightly grease the inside of the new pump housing and install it with the new gasket.
Torque the housing bolts to the manufacturer's recommended specification.
Reinstall the lower unit, ensuring the driveshaft, shift shaft, and water tube align correctly.
Reconnect the battery and start the engine on a water supply to verify a strong water stream from the tell-tale outlet.

Troubleshooting & FAQ

How do I confirm this kit fits my specific engine?

The most reliable method is to match your engine's model, year, and (if applicable) serial number against the compatibility tables above. For Suzuki DF90-DF140 models, verifying the serial number is critical, as this kit only fits earlier production engines. Do not rely on appearance alone.

What are the signs of a failing water pump impeller?

Common symptoms include the engine overheating at idle or low speeds, a weak or non-existent water stream from the "tell-tale" outlet, or finding cracked, brittle, or worn-down blades on the old impeller during inspection.

How often should I replace my outboard's impeller?

As a preventative maintenance measure, it is highly recommended to replace the impeller every 1 to 2 years or every 100 to 200 hours of operation, whichever comes first. Usage in saltwater or silty/sandy conditions may require more frequent replacement.

Is this a direct replacement for Suzuki part 17400-92J00?

Yes, this is an aftermarket kit designed to be a direct replacement for Suzuki OEM part number 17400-92J00, as well as several other part numbers from Suzuki, Johnson/Evinrude, and Sierra listed in our Part Number Matrix.

What is included in this water pump kit?

The package contains all the necessary components for a standard water pump service: a new impeller, pump housing, base plate/panel, a full gasket set, and the required installation hardware (screws and washers).

OEM vs. Aftermarket?

This listing is an aftermarket replacement (not OEM). Built to OEM-level specifications with comparable materials. Manufactured in an ISO 9002 facility, batch-inspected for consistency.

Shipping speed & cost

We ship worldwide quickly—typical transit 5–15 days. Standard shipping is free; expedited options appear at checkout where available.

Warranty & returns

Covered by a 1-year warranty against manufacturing defects under normal use. If issues arise, contact support with your order details. Returns are accepted within our standard window (unused & in original condition). See our policy page or reach out for instructions.

Safety & Important Info

Verify images/specifications vs your original part. If anything differs—even if your model appears compatible—do not purchase.
This is an aftermarket replacement, not an OEM component.
Professional installation is recommended for safety and performance.
