Stainless Steel Exhaust Elbow – Fits Yanmar 4LH Series Marine Engin...
Product Details
This Stainless Steel Exhaust Elbow is a direct-fit replacement for Yanmar 4LH series marine diesel engines, primarily found on vessels requiring reliable marine propulsion in the 150-200 HP range.
It serves as an aftermarket replacement for Yanmar part number 119171-13530.
- Designed for marine environments with excellent corrosion resistance.
- Direct replacement for straightforward installation.
- Constructed from high-grade stainless steel (INOX) for extended service life.
Part Number Matrix
Use this matrix to confirm equivalent references across OEM and aftermarket.
| Brand | Part Number |
|---|---|
| Yanmar | 119171-13530 |
Engine & Model Compatibility
Confirm your engine model/year in the table below.
| Brand | Model | Stroke | OEM Part No. | Notes |
|---|---|---|---|---|
| Yanmar | 4LH-DTZ | 4-Stroke | 119171-13530 | |
| Yanmar | 4LH-DTE | 4-Stroke | 119171-13530 | |
| Yanmar | 4LH Series | 4-Stroke | 119171-13530 | Exact model compatibility needs verification |
Technical Specs
- Product Type
- Marine Exhaust Elbow
- Installation
- Direct Replacement
- Fuel Type
- Diesel
- Connection
- Inlet: 1-1/4" (31.75 mm), Outlet: 3-1/2" (88.9 mm)
- Housing Material
- Stainless Steel (INOX)
- Housing Color
- Silver/Metallic
- Dimensions
- Length: 22.2 cm, Width: 21.1 cm, Height: 12.6 cm
- Weight
- 5.0 kg (11.0 lb)
- Fitting Type
- Direct Fit
- Other Technical Attributes
- Designed for marine environments with excellent corrosion resistance
What’s in the Box
- 1 x Exhaust Elbow (119171-13530)
*Note: Recommended to use with gasket REC119171-13510 (sold separately).
Installation Notes
- Ensure the engine is completely cool and disconnect the battery before starting.
- Drain engine coolant to a level below the exhaust manifold to prevent spills.
- Carefully remove the old exhaust elbow, disconnecting any attached hoses or sensors.
- Thoroughly clean the mating surface on the exhaust manifold, removing all old gasket material and debris.
- Position the new gasket (sold separately) on the manifold before fitting the elbow.
- Install the new stainless steel exhaust elbow, ensuring correct alignment.
- Tighten the mounting bolts to the manufacturer's specified torque settings. Do not overtighten.
- Reconnect all hoses and sensors, ensuring secure connections.
- Refill the cooling system, start the engine, and carefully inspect for any exhaust or coolant leaks.
Troubleshooting & FAQ
How do I know if this exhaust elbow fits my specific engine model?
This elbow is designed for the Yanmar 4LH series. Always compare the part number (119171-13530), dimensions, and photos on this page to your existing part before ordering. If your model is in the 4LH series but you are unsure, verifying with a mechanic is recommended.
What are common signs that my exhaust elbow is failing?
Signs of a failing exhaust elbow include water leaks (external or internal), engine overheating, loss of power, excessive smoke, or visible corrosion and cracks on the elbow itself. A leaking elbow can cause catastrophic engine damage if not replaced promptly.
What is the advantage of a stainless steel elbow versus an OEM cast iron one?
Stainless steel offers superior corrosion resistance compared to traditional cast iron, especially in harsh saltwater environments. This extends the part's service life and reduces the risk of leaks and blockages over time.
Do I need to use a new gasket for installation?
Yes, it is highly recommended to use a new gasket (such as REC119171-13510, sold separately) during installation to ensure a proper, leak-free seal between the elbow and the manifold.
How often should a marine exhaust elbow be inspected?
Regular inspection during routine engine maintenance (at least annually) is critical. However, replacement intervals can vary widely based on usage (freshwater vs. saltwater), operating hours, and engine temperature. Replace it immediately if any signs of failure are detected.
OEM vs. Aftermarket?
This listing is an aftermarket replacement (not OEM). Built to OEM-level specifications with comparable materials. Manufactured in an ISO 9002 facility, batch-inspected for consistency.
Shipping speed & cost
We ship worldwide quickly—typical transit 5–15 days. Standard shipping is free; expedited options appear at checkout where available.
Warranty & returns
Covered by a 1-year warranty against manufacturing defects under normal use. If issues arise, contact support with your order details. Returns are accepted within our standard window (unused & in original condition). See our policy page or reach out for instructions.
Safety & Important Info
- Verify images/specifications vs your original part. If anything differs—even if your model appears compatible—do not purchase.
- This is an aftermarket replacement, not an OEM component.
- Professional installation is recommended for safety and performance.
