Stainless Steel Thrust Washer – Fits Parsun/Yamaha 5HP Outboards (Replaces PAF4-03000026)
Stainless Steel Thrust Washer – Fits Parsun/Yamaha 5HP Outboards (Replaces PAF4-03000026) is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Worry-free returns
Worry-free returns
You may return most new, unopened items within 7 days of delivery for a full refund. We'll also pay the return shipping costs if the return is a result of our error (you received an incorrect or defective item, etc.).
You should expect to receive your refund within four weeks of giving your package to the return shipper, however, in many cases you will receive a refund more quickly. This time period includes the transit time for us to receive your return from the shipper (5 to 10 business days), the time it takes us to process your return once we receive it (3 to 5 business days), and the time it takes your bank to process our refund request (5 to 10 business days).
If you need to return an item, simply login to your account, view the order using the "Complete Orders" link under the My Account menu and click the Return Item(s) button. We'll notify you via e-mail of your refund once we've received and processed the returned item.
Delivery and Shipping
Delivery and Shipping
Free standard shipping on all orders under 1 KG
Stainless Steel Thrust Washer – Fits Parsun/Yamaha 5HP Outboards (R...
Product Details
This high-quality Stainless Steel Thrust Washer is an essential component for the propeller shaft assembly on Parsun and Yamaha 4–5HP 4-stroke outboards. It is designed to fit a range of models, including the Parsun F4, F5, and the F2.6 lower unit, ensuring reliable performance and durability in marine environments.
This part serves as a direct replacement for Yamaha part number 90201-08M54 and Parsun part numbers PAF4-03000026 and F4-03000026.
- Installs on the propeller shaft between the gearcase housing and the propeller.
- Constructed from corrosion-resistant stainless steel for extended service life.
- Engineered to meet or exceed original equipment manufacturer (OEM) specifications for fit and function.
Part Number Matrix
Use this matrix to confirm equivalent references across OEM and aftermarket brands.
| Brand | Part Number |
|---|---|
| Parsun | PAF4-03000026 |
| Parsun | F4-03000026 |
| Yamaha | 90201-08M54 |
Engine & Model Compatibility
Confirm your engine model and part number in the table below.
For Parsun Owners: This washer is a direct fit for F4 and F5 models and is also used in the lower unit assembly of the F2.6 outboard.
For Yamaha Owners: This component is compatible with various 4-stroke outboards in the 4HP to 5HP range that specify part number 90201-08M54.
| Brand | Model | Rated HP | Stroke | OEM Part No. | Notes |
|---|---|---|---|---|---|
| Parsun | F2.6 | 2.6 | 4-Stroke | F4-03000026 | Used in lower unit assembly |
| Parsun | F4 | 4 | 4-Stroke | PAF4-03000026 | Primary application |
| Parsun | F5 | 5 | 4-Stroke | PAF4-03000026 | Primary application |
| Yamaha | [Various] | 4-5 | 4-Stroke | 90201-08M54 | Compatible with multiple models |
Technical Specs
- Product Type
- Stainless Steel Thrust Washer
- Installation
- Propeller Shaft Assembly
- Housing Material
- Stainless Steel
- Dimensions
- 0.5 cm × 5.5 cm × 10.0 cm (H × W × L)
- Weight
- 0.03 kg (0.07 lb)
- Position
- Located between thrust washer and propeller on propeller shaft
What’s in the Box
- 1 × Stainless Steel Washer (replaces PAF4-03000026/90201-08M54)
Installation Notes
- Ensure the engine is completely off and shifted into neutral. Secure the propeller to prevent accidental rotation.
- Remove the cotter pin from the propeller nut, then unscrew the nut and remove the outer washer.
- Carefully slide the propeller off the splined shaft.
- Remove the old thrust washer positioned against the gearcase housing.
- Clean the propeller shaft of any debris or fouling.
- Slide the new stainless steel thrust washer onto the shaft until it sits flush against the housing.
- Reinstall the propeller, ensuring it engages correctly with the shaft splines.
- Replace the outer washer, tighten the propeller nut to the manufacturer's recommended torque, and secure it with a new cotter pin.
Troubleshooting & FAQ
What are the signs of a worn thrust washer?
Symptoms of a failing thrust washer include excessive propeller vibration, a distinct rattling or grinding noise from the lower unit while in gear, and visible signs of scoring, cracking, or deformation on the washer itself upon inspection.
Will this fit other Parsun or Yamaha horsepower models?
This part is specifically designed for Parsun/Yamaha 4-5HP 4-stroke models. Using it on other models is not recommended unless your service manual explicitly lists part numbers PAF4-03000026 or 90201-08M54 as compatible.
How often should this part be replaced?
Thrust washers do not have a fixed replacement interval. They should be inspected for wear or damage whenever the propeller is removed for service. Replace it if you notice any scoring, warping, or significant thinning.
OEM vs. Aftermarket?
This listing is an aftermarket replacement (not OEM). Built to OEM-level specifications with comparable materials. Manufactured in an ISO 9002 facility, batch-inspected for consistency.
Shipping speed & cost?
We ship worldwide quickly—typical transit 5–15 days. Standard shipping is free; expedited options appear at checkout where available.
Warranty & returns?
Covered by a 1-year warranty against manufacturing defects under normal use. If issues arise, contact support with your order details. Returns are accepted within our standard window (unused & in original condition). See our policy page or reach out for instructions.
Safety & Important Info
- Verify images/specifications vs your original part. If anything differs—even if your model appears compatible—do not purchase.
- This is an aftermarket replacement, not an OEM component.
- Professional installation is recommended for safety and performance.
