Sherwood Major Repair Kit with 10615 Impeller – Fits Sherwood P102, P105 and P109 Pumps (Replaces Sherwood 19354)
Sherwood Major Repair Kit with 10615 Impeller – Fits Sherwood P102, P105 and P109 Pumps (Replaces Sherwood 19354) is backordered and will ship as soon as it is back in stock.
Worry-free returns
Worry-free returns
Shop with confidence. If you’re not completely satisfied, eligible items may be returned within the return window, provided they are unused and in original packaging.
If the return is due to our error or a defective item, we’ll make it right.
Please contact us before returning any item.
Delivery and Shipping
Delivery and Shipping
Orders are typically processed within 1–2 business days.
U.S. orders usually arrive within 6–15 days, depending on stock location and destination.
International delivery times may vary due to customs processing.
Tracking information will be provided once your order ships.
Sherwood Major Repair Kit with 10615 Impeller – Fits Sherwood P102,...
Sherwood Major Repair Kit with 10615 Impeller – Fits Sherwood P102, P105 and P109 Pumps (Replaces Sherwood 19354) is backordered and will ship as soon as it is back in stock.
Product Details
This Sherwood Major Repair Kit with 10615 Impeller provides the wear components needed to rebuild selected Sherwood crank-driven raw-water pumps. It is designed for Sherwood pump models P102, P105 and P109, which are used in a range of inboard marine applications.
The kit is a replacement for the Sherwood 19354 major repair kit reference. Confirm the pump model, cover style and component arrangement before ordering, especially when servicing an older pump or a pump that has previously been rebuilt.
- Application: Mechanical raw-water pump rebuild.
- Impeller: Includes a 12-blade 10615 impeller.
- Fitment: Sherwood P102, P105 and P109 pump models.
- Gasket note: The supplied end-cover gasket is intended for the applicable later-style pump configuration; compare it with the gasket or O-ring removed from your pump.
Part Number Reference
Use the following reference to compare the kit with the applicable Sherwood pump-repair listing. Part-number references do not replace verification of the pump model and cover configuration.
| Brand | Part Number | Reference |
|---|---|---|
| Sherwood | 19354 | Major repair kit reference |
| Sherwood | 10615 | Impeller reference included with this kit |
Technical Specs
- Product Type
- Marine raw-water pump major repair kit
- Installation
- Mechanical
- Impeller
- 10615, 12-blade marine impeller
- Impeller Material
- Neoprene
- Shaft Connection
- 5/8 in (16 mm)
- Drive Type
- 3/16 in key drive
What's in the Box
- 1 x Cam
- 1 x Cam screw
- 1 x Cam screw washer
- 2 x Bearings
- 1 x Small external retaining ring
- 1 x Large internal retaining ring
- 1 x Key
- 1 x Lip seal
- 1 x 10615 impeller
- 1 x O-ring
- 1 x End-cover gasket for the applicable later-style pump configuration
Installation Notes
- Disconnect the vessel battery and close the raw-water intake seacock.
- Place a catch pan under the pump and drain remaining water by loosening the hoses as needed.
- Remove the pump end-cover screws, cover and old gasket or O-ring.
- Carefully remove the old impeller. Use an impeller puller if necessary and avoid damaging the pump housing.
- Inspect the housing, shaft and cover for scoring, corrosion or other damage. Clean all mating surfaces thoroughly.
- Replace the lip seal, bearings and retaining rings with the supplied components.
- Apply a small amount of non-petroleum-based lubricant, such as silicone lubricant or soapy water, to the impeller and housing.
- Install the impeller with a twisting motion in the direction of shaft rotation. Do not force it onto the shaft; it must move freely for the pump to prime correctly.
- Install the key, cam and cam-screw components.
- Fit the correct new gasket or O-ring and securely fasten the end cover.
- Reconnect the hoses, open the seacock fully and reconnect the battery.
- After starting the engine, immediately check the pump and hose connections for leaks and confirm normal raw-water flow.
Troubleshooting & FAQ
What Sherwood pump models does this kit fit?
This major repair kit is listed for Sherwood raw-water pump models P102, P105 and P109. Verify the pump identification and cover configuration before ordering.
Does this kit fit every P102, P105 or P109 pump?
Not necessarily. Pump revisions may use different covers, gaskets or internal arrangements. Compare the supplied gasket or O-ring, key, cam and other components with your existing pump before installation.
What impeller is included?
The kit includes a 10615 12-blade impeller. The impeller reference should not be confused with a complete major repair kit.
What are the signs of a failing water-pump impeller?
Common symptoms include higher-than-normal engine temperature, reduced water flow from the exhaust, damaged or missing impeller blades, and water leakage from the pump housing or seal area.
How should the new impeller be lubricated?
Use a non-petroleum-based lubricant, such as silicone lubricant or soapy water. Do not force the impeller onto the shaft, and do not use petroleum-based grease on the neoprene impeller.
When should the impeller be replaced?
Inspect the impeller during routine pump maintenance and replace it when blades show tearing, cracking, distortion or other damage. Replacement intervals depend on operating hours, water conditions and storage practices.
Is this an OEM Sherwood part?
This listing is for an aftermarket replacement repair kit, not a genuine OEM Sherwood kit. Sherwood and the referenced part numbers are used only to identify the applicable pump and replacement references.
What are the shipping speed and cost?
Typical international transit is 5–15 days. Standard shipping is free to most regions; available expedited options and charges are shown at checkout.
What is the warranty and return policy?
This product is covered by a 1-year warranty against manufacturing defects under normal use. Returns are accepted within the standard return period for unused items in their original condition. Contact support for return instructions.
Safety & Important Information
- Confirm the pump model and compare the new components with the original parts before installation.
- Close the seacock and disconnect the battery before servicing the raw-water pump.
- This is an aftermarket replacement kit, not a genuine OEM component.
- Professional installation is recommended when pump, shaft or housing damage is present.
