Product Details
This Water Pump Impeller – Fits Johnson/Evinrude 2–4HP Outboards (Replaces 396852, 433935, 767407) is engineered for compatibility with a wide range of Johnson and Evinrude outboard motors from 2HP to 4HP, covering models manufactured between 1987 and 2006. It serves as a direct-fit replacement to restore your engine’s cooling system performance.
It interchanges with OEM part numbers 0767407, 0433935, 0769221, and 0396852, as well as aftermarket equivalents like Sierra 18-3015 and CEF 500332.
- For proper installation, always lubricate the impeller and housing with glycerine, silicone grease, or dish soap.
- Constructed from a durable neoprene and metal alloy with a brass hub for reliable, long-term service in marine environments.
- Features a 3-blade design precision-molded for optimal water flow.
Part Number Matrix
Use this matrix to confirm equivalent references across OEM and aftermarket.
| Brand | Part Number |
|---|---|
| Johnson/Evinrude (OEM) | 0767407 |
| Johnson/Evinrude (OEM) | 0433935 |
| Johnson/Evinrude (OEM) | 433935 |
| Johnson/Evinrude (OEM) | 0769221 |
| Johnson/Evinrude (OEM) | 769221 |
| Johnson/Evinrude (OEM) | 0396852 |
| Johnson/Evinrude (OEM) | 396852 |
| Sierra (Aftermarket) | 18-3015 |
| CEF (Aftermarket) | 500332 |
Engine & Model Compatibility
Confirm your engine model/year in the table below.
For Johnson/Evinrude engines, this part widely fits 2-stroke models from 2HP to 4HP manufactured between 1987 and 2006. Please check the specific model codes listed for your horsepower and year.
| Brand | Model | Rated HP | Stroke | Years | OEM Part No. | Notes |
|---|---|---|---|---|---|---|
| Johnson/Evinrude | General 2-stroke models | 2HP | 2-Stroke | 2001 | 0767407, 0433935, 0769221, 0396852 | Fits 2 hp E2WRSIR, J2RTSIA, J2RTVSIA, J2WRSIR |
| Johnson/Evinrude | General 2-stroke models | 2.5HP | 2-Stroke | 1987–1988 | 0767407, 0433935, 0769221, 0396852 | Fits 2.5 hp E3RCCM, E3RCUA, J3RCCM, J3RCUA |
| Johnson/Evinrude | General 2-stroke models | 3HP | 2-Stroke | 1989–1997, 2001 | 0767407, 0433935, 0769221, 0396852 | Fits 3 hp BE3REDS, BJ3REDS, E3BRCEC, E3BRESR, E3REIA, E3RENM, E3REOD, E3RERE, E3RETB, E3REUC, E3ROSIA, E3WRSIR, J3BRCEC, J3BRESR, J3REIA, J3RENM, J3REOD, J3RERE, J3RETB, J3REUC, J3RTLSIA, J3RTSIA, J3RTVSIA, J3WRSIR, SJ3REDS |
| Johnson/Evinrude | General 2-stroke models | 3.5HP | 2-Stroke | 2002–2006 | 0767407, 0433935, 0769221, 0396852 | Fits 3.5 hp J3RSDE, J3RSNF, J3RSOD, J3RSRE, J3RSTB, J3RSTF |
| Johnson/Evinrude | Ultra & Excel | 4HP | 2-Stroke | 1987–2006 | 0767407, 0433935, 0769221, 0396852 | Fits 4 hp BE4BREDS, BE4BREUC, BE4BRLEDS, BE4BRLEUC, BE4RDHEDS, BE4RDHLEDS, BE4REDS, BE4RLEDS, BJ4BREDS, BJ4BREUC, BJ4BRLEDS, BJ4BRLEUC, BJ4RDHEDS, BJ4RDHLEDS, BJ4REDS, BJ4RLEDS, E4BRECRJ, E4BRHCCS, E4BRHLCCS, E4BRLECRJ, E4RCCS, E4RCEC, E4RCUD, E4RDHCEC, E4RDHEIA, E4RDHENM, E4RDHEOD, E4RDHERE, E4RDHESR, E4RDHETB, E4RDHLCEC, E4RDHLEIA, E4RDHLENM, E4RDHLEOD, E4RDHLERE, E4RDHLESR, E4RDHLETB, E4REDS, E4REIA, E4RENM, E4REOD, E4RERE, E4RESR, E4RETB, E4REUC, E4RLCCS, E4RLCEC, E4RLCUD, E4RLEDS, E4RLEIA, E4RLENM, E4RLEOD, E4RLERE, E4RLESR, E4RLETB, E4RLEUC, J4BRECRJ, J4BRHCCS, J4BRHLCCS, J4BRLECRJ, J4RCCS, J4RCEC, J4RCUD, J4RDHCEC, J4RDHEIA, J4RDHENM, J4RDHEOD, J4RDHERE, J4RDHESR, J4RDHETB, J4RDHLCEC, J4RDHLEIA, J4RDHLENM, J4RDHLEOD, J4RDHLERE, J4RDHLESR, J4RDHLETB, J4REDS, J4REEA, J4REIA, J4RENM, J4REOD, J4RERE, J4RESR, J4RETB, J4REUC, J4RLCCS, J4RLCEC, J4RLCUD, J4RLEDS, J4RLEEA, J4RLEIA, J4RLENM, J4RLEOD, J4RLERE, J4RLESR, J4RLETB, J4RLEUC, J4RLSIB, J4RLSSM, J4RSIB, J4RSSM, SJ4REDS, SJ4RLEDS |
Technical Specs
- Product Type
- Water Pump Impeller
- Use
- Engine Cooling Systems (Water)
- Blades
- 3
- Shaft Style
- Key Drive
- Material
- Neoprene and Metal Alloy / Brass Hub
- Product Dimensions
- Height: 3.2 in; Width: 2.0 in; Length: 3.2 in
- Weight
- 19.84 g (0.7 oz) – 24 g (0.84 oz)
What’s in the Box
- 1 x Water Pump Impeller
Installation Notes
- Disconnect the battery and remove the engine cover.
- Place the gear shifter in forward or neutral and unbolt the lower unit (gearcase) from the upper engine housing.
- Carefully lower and remove the gearcase to access the water pump assembly.
- Unbolt and remove the water pump housing cover.
- Remove the old impeller, taking note of the direction of the fins.
- Clean any debris or corrosion from the pump housing, wear plate, and driveshaft.
- Lightly lubricate the interior of the pump housing and the new impeller with silicone grease or dish soap.
- Install the new impeller onto the driveshaft, rotating it in the direction of engine rotation to bend the fins correctly.
- Reinstall the water pump housing, reassemble the gearcase, and bolt it back to the engine.
Troubleshooting & FAQ
How do I confirm this impeller is the right one for my motor?
The best method is to match your existing OEM part number to the numbers in our Part Number Matrix. Additionally, check your engine's model, HP, and year against our detailed compatibility table. Visual comparison to your old part is also recommended.
What are common signs of a bad or failing water pump impeller?
The most common symptoms include the engine overheating at idle or low speeds, and a weak or non-existent stream of water from the "tell-tale" outlet. Reduced engine performance can also be a sign.
How often should I replace the water pump impeller?
As a preventative maintenance item, it is recommended to replace the impeller every 1-2 years or every 100-200 hours of use, whichever comes first. This interval can be shorter if you frequently operate in sandy, silty, or saltwater conditions.
What is the difference between this part and the OEM version?
This is a high-quality aftermarket part designed to meet or exceed OEM specifications. It is made from comparable materials (neoprene and brass hub) to ensure reliable performance and a proper fit, offering a cost-effective solution to the original.
Can I install this impeller myself?
Yes, this is a common DIY task for boat owners with basic mechanical skills and tools. The key is to ensure the new impeller fins are bent in the right direction upon installation and to lubricate the housing well.
The listed warranty information seems to vary. What warranty applies?
Different aftermarket brands may offer different warranties (e.g., 1-year vs. limited lifetime). This specific product sold by Sea Sierra is covered by our standard 1-year manufacturer warranty against defects. Please see our warranty policy for full details.
What is the difference between an OEM and an Aftermarket part?
This listing is an aftermarket replacement (not OEM). It has been built to OEM-level specifications with comparable materials. All parts are manufactured in an ISO 9002 facility and are batch-inspected for consistency and quality.
How fast do you ship and what are the costs?
We ship worldwide quickly—typical transit time is 5–15 days. Standard shipping is free to most locations, with expedited options available at checkout where applicable.
What is your warranty and returns policy?
This product is covered by a 1-year warranty against manufacturing defects under normal use. If you encounter any issues, please contact our support team with your order details. Returns are accepted within our standard window for unused items in their original condition. See our policy page or reach out for instructions.
Safety & Important Info
- Always verify images and specifications against your original part before purchasing. If anything differs—even if your model appears compatible—do not purchase.
- This is an aftermarket replacement part, not an OEM component. Brand names and part numbers are used for reference purposes only.
- Professional installation is highly recommended for safety and to ensure proper performance. Incorrect installation can lead to engine damage.
