Cylinder Head Gasket – Fits Johnson/Evinrude 200/225/250 HP V6 Engi...
Product Details
This Cylinder Head Gasket provides a precision seal for Johnson/Evinrude 90° V6 200-250 HP 3.3L Loopcharged engines manufactured between 1994 and 2001. It is engineered as a high-quality replacement to restore engine integrity and performance.
This part serves as a direct cross-reference for multiple part numbers, including Sierra Marine 18-0492, GLM 36320, Red Rhino OBR JE-513, and BRP/OMC equivalents 778206, 345257, and 0345257.
- Installation: Direct OEM Replacement
- Material: High-strength composite designed for marine environments
- Engine Specifics: Fits V6 models with 3.6875" (93.7 mm) pistons
Part Number Matrix
Use this matrix to confirm equivalent references across OEM and aftermarket.
| Brand | Part Number | Notes |
|---|---|---|
| BRP/OMC | 345257 / 0345257 | Primary OEM Number |
| BRP/OMC | 778206 | Alternate OEM Number |
| BRP/OMC | 0340919 | Superseded by 345257 |
| Sierra Marine | 18-0492 | Aftermarket Interchange |
| GLM | 36320 | Aftermarket Interchange |
| Red Rhino OBR | JE-513 | Aftermarket Interchange |
Engine & Model Compatibility
Confirm your engine model/year in the table below. This part is designed for specific Johnson and Evinrude V6 engines.
| Brand | Model | Rated HP | Stroke | Years | OEM Part No. |
|---|---|---|---|---|---|
| Johnson | J200CXARC, J200CXARK | 200 | 2-Stroke | 1994 | 345257 |
| Johnson | J200CXECM | 200 | 2-Stroke | 1998 | 345257 |
| Johnson | J200CXEDR | 200 | 2-Stroke | 1996 | 345257 |
| Johnson | J200CXEEB, J200CXEEN | 200 | 2-Stroke | 1999 | 345257 |
| Johnson | J200CXEOC | 200 | 2-Stroke | 1995 | 345257 |
| Johnson | J200CXERK, J200CXERS | 200 | 2-Stroke | 1994 | 345257 |
| Johnson | J200CXEUA | 200 | 2-Stroke | 1997 | 345257 |
| Johnson | J200CXSSE | 200 | 2-Stroke | 2000 | 345257 |
| Johnson | J200PLEEB, J200PLEEN | 200 | 2-Stroke | 1999 | 345257 |
| Johnson | J200PLSIF | 200 | 2-Stroke | 2001 | 345257 |
| Johnson | J200PLSSC | 200 | 2-Stroke | 2000 | 345257 |
| Johnson | J200PXEEB, J200PXEEN | 200 | 2-Stroke | 1999 | 345257 |
| Johnson | J200PXSSC | 200 | 2-Stroke | 2000 | 345257 |
| Johnson | J200VXSIF | 200 | 2-Stroke | 2001 | 345257 |
| Johnson | J200VXSSS | 200 | 2-Stroke | 2000 | 345257 |
| Johnson | J225CXARC, J225CXARK | 225 | 2-Stroke | 1994 | 345257 |
| Johnson | J225CXECS | 225 | 2-Stroke | 1998 | 345257 |
| Johnson | J225CXEDE | 225 | 2-Stroke | 1996 | 345257 |
| Johnson | J225CXEEC, J225CXEEN | 225 | 2-Stroke | 1999 | 345257 |
| Johnson | J225CXEOB | 225 | 2-Stroke | 1995 | 345257 |
| Johnson | J225CXERK, J225CXERM | 225 | 2-Stroke | 1994 | 345257 |
| Johnson | J225CXEUD | 225 | 2-Stroke | 1997 | 345257 |
| Johnson | J225CXSSR | 225 | 2-Stroke | 2000 | 345257 |
| Johnson | J225PLEEC, J225PLEEN | 225 | 2-Stroke | 1999 | 345257 |
| Johnson | J225PLSIF | 225 | 2-Stroke | 2001 | 345257 |
| Johnson | J225PLSSR | 225 | 2-Stroke | 2000 | 345257 |
| Johnson | J225PXEEC, J225PXEEN | 225 | 2-Stroke | 1999 | 345257 |
| Johnson | J225PXSSR | 225 | 2-Stroke | 2000 | 345257 |
| Johnson | J225VXSIF | 225 | 2-Stroke | 2001 | 345257 |
| Johnson | J225VXSSS | 225 | 2-Stroke | 2000 | 345257 |
| Johnson | J250CXEEN, J250CXEES | 250 | 2-Stroke | 1999 | 345257 |
| Johnson | J250CXSSS | 250 | 2-Stroke | 2000 | 345257 |
| Johnson | J250VXSIF | 250 | 2-Stroke | 2001 | 345257 |
| Johnson | J250VXSSS | 250 | 2-Stroke | 2000 | 345257 |
| Evinrude | E200CXARC, E200CXARK | 200 | 2-Stroke | 1994 | 345257 |
| Evinrude | E200CXECM | 200 | 2-Stroke | 1998 | 345257 |
| Evinrude | E200CXEDR | 200 | 2-Stroke | 1996 | 345257 |
| Evinrude | E200CXEOC | 200 | 2-Stroke | 1995 | 345257 |
| Evinrude | E200CXERK, E200CXERS | 200 | 2-Stroke | 1994 | 345257 |
| Evinrude | E200CXEUA | 200 | 2-Stroke | 1997 | 345257 |
| Evinrude | E200FCXEEN, E200FCXEES | 200 | 2-Stroke | 1999 | 345257 |
| Evinrude | E200FCXSSC, E200FCXSSH | 200 | 2-Stroke | 2000 | 345257 |
| Evinrude | E200FPLEEN, E200FPLEES | 200 | 2-Stroke | 1999 | 345257 |
| Evinrude | E200FPLSSC, E200FPLSSH | 200 | 2-Stroke | 2000 | 345257 |
| Evinrude | E200FPXEEN, E200FPXEES | 200 | 2-Stroke | 1999 | 345257 |
| Evinrude | E200FPXSSC, E200FPXSSH | 200 | 2-Stroke | 2000 | 345257 |
| Evinrude | E200FSLEEN, E200FSLEES | 200 | 2-Stroke | 1999 | 345257 |
| Evinrude | E200FSLSSC, E200FSLSSH | 200 | 2-Stroke | 2000 | 345257 |
| Evinrude | E200WPXEEN, E200WPXEES | 200 | 2-Stroke | 1999 | 345257 |
| Evinrude | E200WPXSIF | 200 | 2-Stroke | 2001 | 345257 |
| Evinrude | E200WPXSSC | 200 | 2-Stroke | 2000 | 345257 |
| Evinrude | E225CXARC, E225CXARK | 225 | 2-Stroke | 1994 | 345257 |
| Evinrude | E225CXECS | 225 | 2-Stroke | 1998 | 345257 |
| Evinrude | E225CXEDE | 225 | 2-Stroke | 1996 | 345257 |
| Evinrude | E225CXEOB | 225 | 2-Stroke | 1995 | 345257 |
| Evinrude | E225CXERK, E225CXERM | 225 | 2-Stroke | 1994 | 345257 |
| Evinrude | E225CXEUD | 225 | 2-Stroke | 1997 | 345257 |
| Evinrude | E225FCXEEN, E225FCXEEO, E225FCXEES | 225 | 2-Stroke | 1999 | 345257 |
| Evinrude | E225FCXSSC, E225FCXSSH | 225 | 2-Stroke | 2000 | 345257 |
| Evinrude | E225FPLEEN, E225FPLEEO, E225FPLEES | 225 | 2-Stroke | 1999 | 345257 |
| Evinrude | E225FPLSSC, E225FPLSSH | 225 | 2-Stroke | 2000 | 345257 |
| Evinrude | E225FPXEEN, E225FPXEEO, E225FPXEES | 225 | 2-Stroke | 1999 | 345257 |
| Evinrude | E225FPXSSC, E225FPXSSH | 225 | 2-Stroke | 2000 | 345257 |
| Evinrude | E225FPZEEN, E225FPZEEO, E225FPZEES | 225 | 2-Stroke | 1999 | 345257 |
| Evinrude | E225FPZSSC, E225FPZSSH | 225 | 2-Stroke | 2000 | 345257 |
| Evinrude | E250FCXSSS | 250 | 2-Stroke | 2000 | 345257 |
| Evinrude | E250FPXSSS | 250 | 2-Stroke | 2000 | 345257 |
| Evinrude | E250FPZSSS | 250 | 2-Stroke | 2000 | 345257 |
Technical Specs
- Product Type
- Cylinder Head Gasket
- Installation
- Direct OEM Replacement
- Fuel Type
- Gasoline
- Housing Material
- Composite
- Dimensions
- 43.5 cm × 16.5 cm × 0.5 cm (L × W × H)
- Weight
- Approximately 0.28 kg (0.61 lb)
- Bore Size Fitment
- For engines with 3.6875" (93.7 mm) pistons
What’s in the Box
- 1 x Cylinder Head Gasket (Replaces 345257)
Installation Notes
- Disconnect the battery and relieve any pressure in the fuel system.
- Drain the engine coolant completely.
- Remove components obstructing access to the cylinder head, such as the intake and exhaust manifolds.
- Loosen and remove the cylinder head bolts in the reverse order of the manufacturer's specified tightening sequence.
- Carefully lift the cylinder head from the engine block. Avoid prying, which can damage the mating surfaces.
- Thoroughly clean all old gasket material, oil, and debris from the surfaces of the head and block.
- Inspect both mating surfaces for flatness using a straightedge and feeler gauge. Resurface if they are not within specifications.
- Position the new gasket correctly on the engine block, aligning it with any dowel pins.
- Carefully lower the cylinder head back into place over the gasket and dowels.
- Install new or verified head bolts. Tighten them in sequence and stages to the manufacturer's torque specifications.
- Reassemble all components that were previously removed.
- Refill the cooling system, reconnect the battery, and start the engine to check for any leaks.
Troubleshooting & FAQ
How do I know if this gasket will fit my engine?
This gasket is for Johnson/Evinrude 90° V6 3.3L Loopcharged engines (200-250 HP) from 1994–2001 with 3.6875" (93.7 mm) pistons. Always cross-reference your engine's model number with our compatibility list before ordering.
What are the signs of a failed cylinder head gasket?
Common symptoms include engine overheating, a noticeable loss of power, white smoke from the exhaust (burning coolant), milky or frothy engine oil, and bubbling in the radiator or coolant reservoir.
Is this a single gasket or a pair?
This listing is for a single cylinder head gasket. Since V6 engines have two cylinder banks, you will need to purchase two if you are servicing both heads.
Do I need to use sealant with this gasket?
No. This gasket is designed to be installed dry. Applying sealant can interfere with its ability to seal properly, causing hot spots, improper torque, and potential premature failure.
Can I reuse my old head bolts?
It is strongly recommended to use new cylinder head bolts. Old bolts can stretch (yield) upon first use and may not achieve the correct clamping force when re-torqued, leading to leaks and gasket failure.
What is the recommended replacement interval?
Head gaskets are typically replaced only when they fail or during a major engine overhaul, not on a routine service schedule.
OEM vs. Aftermarket?
This listing is an aftermarket replacement (not OEM). Built to OEM-level specifications with comparable materials. Manufactured in an ISO 9001 facility, batch-inspected for consistency.
Shipping speed & cost
We ship worldwide quickly—typical transit 5–15 days. Standard shipping is free; expedited options appear at checkout where available.
Warranty & returns
Covered by a 1-year warranty against manufacturing defects under normal use. If issues arise, contact support with your order details. Returns are accepted within our standard window (unused & in original condition). See our policy page or reach out for instructions.
Safety & Important Info
- Verify images/specifications vs your original part. If anything differs—even if your model appears compatible—do not purchase.
- This is an aftermarket replacement, not an OEM component.
- Professional installation is recommended for safety and performance.
