Refrigeration Relay 501-94141H – Fits Tecumseh TP119AR-021-A2 Compr...
Product Details
This is a high-quality aftermarket Refrigeration Relay 501-94141H, designed as a replacement for True part 802288. It is specifically manufactured for use with the Tecumseh TP119AR-021-A2 compressor found in a wide range of True commercial refrigeration units. This component is crucial for initiating the compressor's start-up sequence.
This part directly interchanges with True 802288 and Embraco part numbers 501-94141H and 8200EMBJ75, ensuring a precise fit and function.
- Designed for direct, plug-in installation (Pin/Terminal connection).
- Constructed from durable, high-quality materials for reliable performance.
- Can be purchased individually or as part of a complete start kit.
Part Number Matrix
Use this matrix to confirm equivalent references across OEM and aftermarket.
| Brand | Part Number |
|---|---|
| True | 802288 |
| Embraco | 501-94141H |
| Embraco | 8200EMBJ75 |
Engine & Model Compatibility
Confirm your equipment model in the table below.
This relay is known to fit the following True refrigeration models. Always verify your specific part number before ordering.
| Brand | Model | OEM Part No. |
|---|---|---|
| True | GDM-10PT | 802288 |
| True | GDM-10PT-LE | 802288 |
| True | GDM-14 | 802288 |
| True | GDM-14RF | 802288 |
| True | GDM-14SL | 802288 |
| True | GDM-23 | 802288 |
| True | GDM-23-2 | 802288 |
| True | GDM-23-FC | 802288 |
| True | GDM-23FC-RF | 802288 |
| True | GDM-23RF | 802288 |
| True | GDM-23W | 802288 |
| True | GDM-23W-RF | 802288 |
| True | GDM-26 | 802288 |
| True | GDM-26RF | 802288 |
| True | GDM-26W | 802288 |
| True | GDM-26W-RF | 802288 |
| True | GDM-33CPT-54 | 802288 |
| True | GDM-33SSL-54-24 | 802288 |
| True | GDM-35SL-RF | 802288 |
| True | GDM-41SL-54 | 802288 |
Technical Specs
- Product Type
- Refrigeration Relay
- Installation
- Direct Replacement
- Connection
- Pin/Terminal
- Housing Color
- Black
- Dimensions
- 20.5 in L × 12.5 in W × 0.5 in H
- Weight
- 0.15 lb (0.068 kg)
- Compatible Compressor
- Tecumseh TP119AR-021-A2
- Manufacturer
- Embraco
- Warranty
- 90 Day Manufacturer Warranty
- Other Technical Attributes
- Can be purchased individually or as part of start kit (213126) for compressor (963040) TPA9421YXA TP119AR-021-E4KX
What’s in the Box
- 1 x Relay (Replaces True 802288)
Installation Notes
- Disconnect the refrigeration unit from its power source completely.
- Access the compressor area, typically located at the bottom rear of the unit.
- Locate the existing relay on the side of the compressor.
- Carefully note the wire connections before unplugging the old relay. Taking a photo is recommended.
- Gently pull the old relay straight off the compressor terminals.
- Align the new relay with the terminal pins on the compressor and press it firmly into place.
- Reconnect the wiring exactly as it was on the original part.
- Restore power to the unit and verify that the compressor starts and runs correctly.
Troubleshooting & FAQ
What are the signs of a failing refrigeration relay?
Common symptoms include the compressor failing to start (you might hear a clicking sound), intermittent cooling, or the compressor running continuously without cycling off. A buzzing or humming from the compressor area without it kicking on is also a strong indicator.
Is this a genuine True or Embraco part?
This is a high-quality aftermarket part designed to meet or exceed OEM specifications. It offers the same fit and function as the original components but at a more competitive price point.
How do I confirm this relay fits my refrigerator?
The best method is to match the part number from your old relay. While our compatibility list is extensive, manufacturers sometimes use different parts for the same model. Visually comparing your old relay to our product photos and checking the compatible compressor model (Tecumseh TP119AR-021-A2) can also confirm fitment.
Can I replace this relay myself?
Yes, this is often a straightforward repair for those with basic mechanical skills. However, it involves working with electrical components. Always ensure the unit is unplugged from power before beginning. If you are not comfortable with the process, we recommend hiring a qualified service technician.
What is the difference between this relay and a start kit?
This is the relay only. A start kit typically includes the relay, an overload protector, and sometimes a start capacitor. If you have diagnosed the relay as the sole point of failure, you only need this part. If other start components are also faulty, a complete kit may be a better solution.
Is any special tool required for installation?
No special tools are generally required. The relay pulls off and pushes onto the compressor terminals by hand. Needle-nose pliers may be helpful for removing and reattaching wire connectors if they are tight.
OEM vs. Aftermarket?
This listing is an aftermarket replacement (not OEM). Built to OEM-level specifications with comparable materials. Manufactured in an ISO 9002 facility, batch-inspected for consistency.
Shipping speed & cost
We ship worldwide quickly—typical transit 5–15 days. Standard shipping is free; expedited options appear at checkout where available.
Warranty & returns
Covered by a 1-year warranty against manufacturing defects under normal use. If issues arise, contact support with your order details. Returns are accepted within our standard window (unused & in original condition). See our policy page or reach out for instructions.
Safety & Important Info
- Verify images/specifications vs your original part. If anything differs—even if your model appears compatible—do not purchase.
- This is an aftermarket replacement, not an OEM component.
- Professional installation is recommended for safety and performance.
