Product Details
This high-quality stainless steel Bravo Rear Anchor Pin is a crucial component for the transom assembly on MerCruiser Bravo sterndrives. It is designed to provide a secure pivot point for the trim cylinders and fits all years of Bravo I, II, III, X, XR, and XZ models.
This part is a direct replacement for multiple OEM and aftermarket part numbers, including Mercury 17-44166 / 17-44166T1, Sierra 18-2461, GLM 21480, and SIE 18-2396, ensuring broad compatibility.
- Installs at the trim cylinder rear anchor point in the transom assembly.
- Constructed from durable stainless steel to resist corrosion in marine environments.
- This complete kit includes the pin, two rubber bushings, two washers, and two nuts.
Part Number Matrix
Use this matrix to confirm equivalent references across OEM and aftermarket.
| Brand | Part Number |
|---|---|
| Mercury | 17-44166 |
| Mercury | 17-44166T1 |
| Sierra | 18-2461 |
| GLM | 21480 |
| SIE | 18-2396 |
Engine & Model Compatibility
Confirm your engine model/year in the table below.
This anchor pin is compatible with a wide range of MerCruiser Bravo series sterndrives, serving as the pivot pin located above the propeller in the trim cylinder assembly.
| Brand | Model | Rated HP | Stroke | Years | OEM Part No. | Notes |
|---|---|---|---|---|---|---|
| MerCruiser | Bravo I | Various | 4-Stroke | All | 17-44166/17-44166T1 | Anchor pin above propeller |
| MerCruiser | Bravo II | Various | 4-Stroke | All | 17-44166/17-44166T1 | Anchor pin above propeller |
| MerCruiser | Bravo III | Various | 4-Stroke | All | 17-44166/17-44166T1 | Anchor pin above propeller |
| MerCruiser | Bravo X | Various | 4-Stroke | All | 17-44166/17-44166T1 | Anchor pin above propeller |
| MerCruiser | Bravo XR | Various | 4-Stroke | All | 17-44166/17-44166T1 | Anchor pin above propeller |
| MerCruiser | Bravo XZ | Various | 4-Stroke | All | 17-44166/17-44166T1 | Anchor pin above propeller |
Technical Specs
- Product Type
- Rear Anchor Pin / Pivot Pin / Tilt Pin
- Installation
- Transom assembly, trim cylinder rear anchor point
- Housing Material
- Stainless steel
- Housing Color
- Silver/metallic
- Dimensions
- Height: 8.75 in; Width: 10.81 in; Length: 1.25 in
- Fitting Type
- Pin with threaded ends
- Thread Size
- 7/16-20
- Other Technical Attributes
- Located above propeller in trim cylinder assembly
What’s in the Box
- 1 x Rear Anchor Pin (17-44166/17-44166T1)
- 2 x Rubber Bushings (23-807073)
- 2 x Washers (12-44163/12-44164)
- 2 x Nuts (11-859116)
Installation Notes
- Ensure the outdrive is in the full down (in) position and disconnect the vessel's battery.
- Adequately support the sterndrive underneath to prevent it from dropping during pin removal.
- Locate the anchor pin connecting the two trim cylinders at the top of the transom assembly.
- Remove the nuts and washers from both threaded ends of the old anchor pin.
- Carefully tap or press the old pin out of the transom assembly and trim cylinders.
- Remove the old rubber bushings from the trim cylinder eyes.
- Clean the pin mounting holes in the transom assembly and cylinder eyes.
- Press the new rubber bushings into the trim cylinder eyes.
- Align the trim cylinders with the transom assembly holes and slide the new anchor pin through.
- Install the new washers and nuts, tightening them to the manufacturer's specified torque.
- Reconnect the battery, test the trim system through its full range of motion, and check for any issues.
Troubleshooting & FAQ
How do I know if this anchor pin fits my sterndrive?
This pin is specifically designed for all MerCruiser Bravo models, including Bravo I, II, III, X, XR, and XZ. To ensure a perfect match, always compare the part numbers (e.g., 17-44166, 18-2461) and dimensions listed on this page against your existing part before ordering.
What are the signs of a failing rear anchor pin?
Common signs of a worn or failing pin include excessive play or "slop" in the sterndrive when trimmed up, clunking sounds during trim operation, or visible corrosion, pitting, and wear on the pin and bushings.
Is this a difficult part to replace?
This task is moderately difficult as it requires securely supporting the full weight of the sterndrive. If you lack the proper equipment or are not comfortable with the procedure, professional installation is highly recommended for safety and to prevent damage.
How often should the anchor pin be inspected or replaced?
It is good practice to inspect the anchor pin and its related hardware (bushings, nuts) annually for any signs of wear, looseness, or corrosion. Replace it immediately if any issues are found to avoid stress on the transom and trim assemblies.
OEM vs. Aftermarket?
This listing is an aftermarket replacement (not OEM). Built to OEM-level specifications with comparable materials. Manufactured in an ISO 9002 facility, batch-inspected for consistency.
Shipping speed & cost?
We ship worldwide quickly—typical transit 5–15 days. Standard shipping is free; expedited options appear at checkout where available.
Warranty & returns?
Covered by a 1-year warranty against manufacturing defects under normal use. If issues arise, contact support with your order details. Returns are accepted within our standard window (unused & in original condition). See our policy page or reach out for instructions.
Safety & Important Info
- Verify images/specifications vs your original part. If anything differs—even if your model appears compatible—do not purchase.
- This is an aftermarket replacement, not an OEM component.
- Professional installation is recommended for safety and performance.
