Water Pump Impeller Kit – Fits Suzuki DF9.9B, DF15A, DF20A (Replaces 17400-94L01, 17400-94L20)
Water Pump Impeller Kit – Fits Suzuki DF9.9B, DF15A, DF20A (Replaces 17400-94L01, 17400-94L20) is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Worry-free returns
Worry-free returns
You may return most new, unopened items within 7 days of delivery for a full refund. We'll also pay the return shipping costs if the return is a result of our error (you received an incorrect or defective item, etc.).
You should expect to receive your refund within four weeks of giving your package to the return shipper, however, in many cases you will receive a refund more quickly. This time period includes the transit time for us to receive your return from the shipper (5 to 10 business days), the time it takes us to process your return once we receive it (3 to 5 business days), and the time it takes your bank to process our refund request (5 to 10 business days).
If you need to return an item, simply login to your account, view the order using the "Complete Orders" link under the My Account menu and click the Return Item(s) button. We'll notify you via e-mail of your refund once we've received and processed the returned item.
Delivery and Shipping
Delivery and Shipping
Free standard shipping on all orders under 1 KG
Water Pump Impeller Kit – Fits Suzuki DF9.9B, DF15A, DF20A (Replace...
Product Details
This Water Pump Impeller Kit – Fits Suzuki DF9.9B, DF15A, DF20A 2013+ (Replaces 17400-94L01) is designed for maintaining the cooling system on Suzuki DF9.9B, DF15A, and DF20A four-stroke outboard models from 2013 and newer. It contains all necessary components to restore the water pump to optimal condition, preventing overheating and ensuring engine longevity.
This kit serves as a direct replacement for Suzuki part numbers 17400-94L01, 17400-94L20, 17400-94L20-000, and JLM Marine 19KS004.
- Installs in the lower unit gearcase.
- Includes a high-quality neoprene impeller, housing sleeve, gaskets, and O-rings.
- Engineered for cooling system maintenance; annual replacement is recommended for reliability.
Part Number Matrix
Use this matrix to confirm equivalent references across OEM and aftermarket suppliers.
| Brand | Part Number |
|---|---|
| Suzuki | 17400-94L01 |
| Suzuki | 17400-94L20 |
| Suzuki | 17400-94L20-000 |
| JLM Marine | 19KS004 |
Engine & Model Compatibility
Confirm your engine model and year in the table below to ensure accurate fitment.
This kit is verified for the following Suzuki outboard engines.
| Brand | Model | Rated HP | Stroke | Years | OEM Part No. |
|---|---|---|---|---|---|
| Suzuki | DF9.9B | 9.9 | 4-Stroke | 2013+ | 17400-94L01 |
| Suzuki | DF15A | 15 | 4-Stroke | 2013+ | 17400-94L01 |
| Suzuki | DF20A | 20 | 4-Stroke | 2013+17400-94L01 |
Technical Specs
- Product Type
- Water Pump Impeller Kit
- Installation
- Lower Unit / Gearcase
- Housing Material
- Stainless Steel, Neoprene Rubber Impeller
- Housing Color
- Silver/Black
- Weight
- 71 g (2.5 oz)
- Other Attributes
- For cooling system maintenance; recommended replacement every 100 hours or annually
What’s in the Box
- 1 x Water Pump Impeller (17411-94J00)
- 1 x Water Pump Case Sleeve (17413-94J00)
- 1 x Pump Plate (17414-94J00)
- 1 x Impeller Key (09204-02004)
- 1 x O-Ring (D:1.9, ID:13) (09280-13004)
- 1 x O-Ring (D:1.9, ID:21.8) (09280-22019)
- 1 x O-Ring (D:2.4, ID:52.6) (09280-54001)
- 1 x Gasket (12X17X1) (09168-12017)
Installation Notes
- Disconnect the battery and remove the engine cover. Disconnect the shift linkage.
- Place the outboard in neutral. Remove the bolts securing the lower unit (gearcase) to the upper casing.
- Carefully lower and separate the gearcase from the drive shaft housing.
- Unbolt and remove the water pump housing to expose the impeller. Note the orientation of the old impeller vanes.
- Remove the old impeller, key, gaskets, and O-rings. Clean all mating surfaces thoroughly.
- Install the new impeller key and place the new impeller into the housing, rotating it in the direction of engine operation to bend the vanes correctly.
- Install the new gaskets, plates, and O-rings. Reassemble the water pump housing and tighten bolts to the manufacturer's specified torque.
- Lightly grease the driveshaft splines and reinstall the lower unit, ensuring the water tube and shift shaft align correctly.
- Secure the gearcase bolts, reconnect the shift linkage, and test the engine in the water, ensuring a steady stream of water from the tell-tale outlet.
Troubleshooting & FAQ
How can I confirm this kit fits my Suzuki outboard?
This kit is specifically for Suzuki DF9.9B, DF15A, and DF20A four-stroke models manufactured from 2013 onwards. Please verify your model and year, and cross-reference the OEM part number (17400-94L01) listed in your owner's manual or on your existing part.
What are the signs of a failing water pump impeller?
Common signs include a weak or non-existent water stream from the "tell-tale" outlet, engine overheating alarms, and in severe cases, steam from the exhaust. Reduced engine performance can also be an indicator.
How often should this water pump kit be replaced?
For preventative maintenance and to ensure engine reliability, we recommend replacing the water pump impeller and gaskets annually or every 100 hours of operation, whichever comes first. This is especially important if you operate in saltwater or sandy/silty conditions.
Is there a difference in performance between this and an OEM kit?
This aftermarket kit is manufactured to meet or exceed OEM specifications for fit, form, and function. The materials, including the neoprene rubber impeller and stainless steel components, are chosen for durability and performance comparable to the original Suzuki parts.
Is the impeller key included?
Yes, the kit is comprehensive and includes the impeller key (OEM ref 09204-02004) along with all necessary gaskets, O-rings, and plates for a complete overhaul.
OEM vs. Aftermarket?
This listing is an aftermarket replacement (not OEM). Built to OEM-level specifications with comparable materials. Manufactured in an ISO 9002 facility, batch-inspected for consistency.
Shipping speed & cost
We ship worldwide quickly—typical transit 5–15 days. Standard shipping is free; expedited options appear at checkout where available.
Warranty & returns
Covered by a 1-year warranty against manufacturing defects under normal use. If issues arise, contact support with your order details. Returns are accepted within our standard window (unused & in original condition). See our policy page or reach out for instructions.
Safety & Important Info
- Verify images and specifications against your original part before purchasing. If anything differs—even if your model appears compatible—do not purchase.
- This is an aftermarket replacement component, not an OEM part.
- Professional installation is recommended for safety and optimal performance.
