Product Details

This wedge-style Transom Saver – Fits Single Ram Outboard Motors (Mercury, Yamaha, Honda, Suzuki, Tohatsu, Evinrude, Johnson) is engineered to protect your boat's transom and your outboard motor’s hydraulic system during trailering. It installs on the single hydraulic ram of your trim/tilt system, where it absorbs road shock and prevents damaging engine movement. It is designed for current single-ram systems on brands including Mercury, Yamaha, Honda, Suzuki, Evinrude, and Tohatsu.

This part serves as a direct replacement for interchange numbers M-Y Wedge M-YU123 and the JLM Marine Transom Saver Support.

Installs in seconds without drilling by clipping directly onto the tilt shaft.
Made from high-density EPDM rubber to withstand compression and temperature extremes.
Includes one transom saver wedge with 10 inner notches for a secure grip on the ram.

Part Number Matrix

Use this matrix to confirm equivalent references across OEM and aftermarket.

Brand	Part Number
M-Y Wedge	M-YU123
JLM Marine	Transom Saver Support

Engine & Model Compatibility

Confirm your engine model/year in the table below.

Mercury: Fits a wide range of current 4-Stroke and 2-Stroke models with single-ram trim/tilt systems. Note that some high-horsepower Verado and Racing models require two units per engine.

Yamaha: Compatible with most modern Portable, Midrange, F115LB, and VMAX-SHO models, as well as older 2-stroke engines equipped with a single trim ram.

Honda: Designed for current BF Series outboards from 40 to 150 HP using a single-ram system.

Suzuki: Fits current DF Series 4-Stroke models from 40 to 200 HP that utilize a single main trim ram.

Evinrude/Johnson: Supports single-ram E-TEC and legacy models from both brands up to 130 HP.

Tohatsu/Nissan: Covers a variety of current Tohatsu and older Nissan 4-Stroke outboards from 40 to 150 HP.

Brand	Model	Rated HP	Stroke	Years	Notes
Mercury	Four-Stroke, SeaPro	40-175 HP	4-Stroke	Current models	Single main tilt shaft
Mercury	ProXS, SeaPro	40-175 HP	2-Stroke/4-Stroke	Current models	Single-ram trim/tilt
Mercury	Verado V6/V8	250-400 HP	4-Stroke	Current models	Requires TWO units
Mercury	Racing	300R-500R	4-Stroke	Current models	Requires TWO units
Mercury	Racing	60R	4-Stroke	Current models	Single unit
Yamaha	Portable/Midrange	9.9-90 HP	4-Stroke	Current models	Single-ram trim/tilt
Yamaha	F115LB	115 HP	4-Stroke	Current models	Single-ram trim/tilt
Yamaha	VMAX-SHO	90-115 HP	4-Stroke	Current models	Single-ram trim/tilt
Yamaha	Various	30-115 HP	2-Stroke	Older models	Single-ram trim/tilt
Honda	BF Series	40-150 HP	4-Stroke	Current models	Single-ram trim/tilt
Suzuki	DF Series	40-200 HP	4-Stroke	Current models	Single-ram trim/tilt
Evinrude	E-TEC H.O. & Inline	25-130 HP	2-Stroke	Up to 2020	Single-ram trim/tilt
Johnson	Various	25-130 HP	2-Stroke/4-Stroke	Older models	Single-ram trim/tilt
Tohatsu	Various	40-150 HP	4-Stroke	Current models	Single-ram trim/tilt
Nissan	Various	40-150 HP	4-Stroke	Older models	Single-ram trim/tilt

Technical Specs

Product Type: Transom Saver / Motor Support
Installation: No drilling; attaches directly to single ram tilt shaft
Connection: Direct mount to hydraulic ram
Housing Material: High-density EPDM rubber
Housing Color: Black
Dimensions: Approximately 127 mm (5 inches) long
Fitting Type: Universal for single ram trim/tilt systems
Working Pressure: Over 907 kg (2,000 lbs) compression rating
Operating Temperature: Rated for extreme hot/cold temperatures
Warranty: 1 year against manufacturing defects (JLM Marine)
Other Technical Attributes: Features 10 inner notches to ensure secure connection to tilt shaft

What’s in the Box

1 x Transom Saver Wedge

Installation Notes

Tilt your outboard motor to its highest position to fully extend the trim/tilt ram.
Securely clip the transom saver wedge onto the exposed single hydraulic ram shaft.
Slowly lower the motor until it applies firm pressure to the wedge, creating a stable cushion.
Before trailering, always confirm the motor is snug against the wedge and cannot bounce or sway.

Troubleshooting & FAQ

How do I know if this wedge fits my outboard motor?

This transom saver is designed for outboard motors with a single main trim/tilt ram. Check our compatibility table for specific brands, models, and HP ranges. If your motor has twin rams (like some high-HP Mercury Verado models), you will need two units. Always visually inspect your motor's hydraulic system to confirm it has one central ram before ordering.

Is this better than a traditional transom saver bar?

A wedge-style saver offers a different approach. It stabilizes the engine by cushioning the hydraulics, absorbing road shock directly at the ram. Traditional bars transfer this force to the trailer frame. Wedges are faster to install, require no drilling, and take up less storage space. The best choice depends on your boat, trailer configuration, and personal preference.

My Mercury Verado requires two units. How do I install them?

For engines like the Mercury Verado V6/V8 and some Racing models that have two hydraulic trim rams, you must use two transom saver wedges. Place one wedge on each of the two rams before lowering the engine. This ensures the load is distributed evenly, providing stable support during transit.

How often should I inspect the transom saver?

Inspect the wedge before each use. Look for any signs of cracking, splitting, or deformation in the rubber. Exposure to UV rays, fuel, or oil can degrade the material over time. Replace it immediately if you notice any damage that could compromise its ability to support the engine.

What are the signs of a failing transom saver?

A failing wedge may show visible cracks or have a "squashed" appearance, indicating it has lost its compressive strength. During trailering, you might notice more engine bounce than usual. If the wedge no longer fits snugly on the ram or falls off easily, it's time for a replacement.

Can I trim my motor up or down with the wedge installed?

No. The wedge is designed to lock the engine in a partially tilted position for trailering only. Attempting to operate the trim/tilt system with the wedge installed can damage the hydraulic pump, the motor, or the wedge itself. Always remove it before launching your boat or operating the engine.

OEM vs. Aftermarket?

This listing is an aftermarket replacement (not OEM). Built to OEM-level specifications with comparable materials. Manufactured in an ISO 9002 facility, batch-inspected for consistency.

Shipping speed & cost?

We ship worldwide quickly—typical transit 5–15 days. Standard shipping is free; expedited options appear at checkout where available.

Warranty & returns?

Covered by a 1-year warranty against manufacturing defects under normal use. If issues arise, contact support with your order details. Returns are accepted within our standard window (unused & in original condition). See our policy page or reach out for instructions.

Safety & Important Info

Verify images/specifications vs your original part. If anything differs—even if your model appears compatible—do not purchase.
This is an aftermarket replacement, not an OEM component.
Professional installation is recommended for safety and performance.
