Aftercooler Gasket Kit – Fits Volvo Penta D31/D41/D32/D42/D43/D44/D13 Diesel Engines (Replaces 858570, 22109)
Aftercooler Gasket Kit – Fits Volvo Penta D31/D41/D32/D42/D43/D44/D13 Diesel Engines (Replaces 858570, 22109) is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Worry-free returns
Worry-free returns
You may return most new, unopened items within 7 days of delivery for a full refund. We'll also pay the return shipping costs if the return is a result of our error (you received an incorrect or defective item, etc.).
You should expect to receive your refund within four weeks of giving your package to the return shipper, however, in many cases you will receive a refund more quickly. This time period includes the transit time for us to receive your return from the shipper (5 to 10 business days), the time it takes us to process your return once we receive it (3 to 5 business days), and the time it takes your bank to process our refund request (5 to 10 business days).
If you need to return an item, simply login to your account, view the order using the "Complete Orders" link under the My Account menu and click the Return Item(s) button. We'll notify you via e-mail of your refund once we've received and processed the returned item.
Delivery and Shipping
Delivery and Shipping
Free standard shipping on all orders under 1 KG
Aftercooler Gasket Kit – Fits Volvo Penta D31/D41/D32/D42/D43/D44/D...
Product Details
This Aftercooler Gasket Kit – Fits Volvo Penta D31/D41/D32/D42/D43/D44/D13 Diesel Engines is designed for a precise fit on a range of Volvo Penta marine diesel engines. It is compatible with the AD/TAMD/TMD 31 and 41 series, as well as the KAD/KAMD 32, 42, 43, 44, and 300 series manufactured between 1991 and 2005.
This kit serves as a direct replacement for Volvo Penta part number 858570 and Orbitrade Marine 22109.
- Installs as a direct replacement service part.
- Engineered to seal the aftercooler and heat exchanger connection.
- Designed for use in marine diesel engine environments.
Part Number Matrix
Use this matrix to confirm equivalent references across OEM and aftermarket.
| Brand | Part Number |
|---|---|
| Volvo Penta | 858570 |
| Volvo Penta | REC858570 |
| Orbitrade Marine | 22109 |
Engine & Model Compatibility
Confirm your engine model and year in the table below.
Compatible with the following Volvo Penta models:
| Brand | Model | Stroke | Years | OEM Part No. |
|---|---|---|---|---|
| Volvo Penta | AD31D, AD31D-A | 4-Stroke | 1993–1994 | 858570 |
| Volvo Penta | AD31L-A | 4-Stroke | 1994–2004 | 858570 |
| Volvo Penta | AD31P-A | 4-Stroke | 1994–2004 | 858570 |
| Volvo Penta | AD31XD | 4-Stroke | 1993–1994 | 858570 |
| Volvo Penta | TAMD31D | 4-Stroke | 1993–1994 | 858570 |
| Volvo Penta | TAMD31L-A | 4-Stroke | 1994–2003 | 858570 |
| Volvo Penta | TAMD31M-A | 4-Stroke | 1994–2003 | 858570 |
| Volvo Penta | TAMD31P-A | 4-Stroke | 1994–2004 | 858570 |
| Volvo Penta | TMD31D | 4-Stroke | 1993–1994 | 858570 |
| Volvo Penta | TMD31L-A | 4-Stroke | 1994–1997 | 858570 |
| Volvo Penta | KAD32P-A | 4-Stroke | 1996–2005 | 858570 |
| Volvo Penta | AD41D | 4-Stroke | 1993–1994 | 858570 |
| Volvo Penta | AD41L-A | 4-Stroke | 1994–2004 | 858570 |
| Volvo Penta | AD41P-A | 4-Stroke | 1994–2004 | 858570 |
| Volvo Penta | D41D, D41L-A | 4-Stroke | 1993–1994 | 858570 |
| Volvo Penta | TAMD41D | 4-Stroke | 1993–1994 | 858570 |
| Volvo Penta | TAMD41H-A | 4-Stroke | 1998–2004 | 858570 |
| Volvo Penta | TAMD41L-A | 4-Stroke | 1994–2000 | 858570 |
| Volvo Penta | TAMD41M-A | 4-Stroke | 1994–2004 | 858570 |
| Volvo Penta | TAMD41P-A | 4-Stroke | 1994–2005 | 858570 |
| Volvo Penta | TMD41D | 4-Stroke | 1993–1994 | 858570 |
| Volvo Penta | TMD41L-A | 4-Stroke | 1994–1997 | 858570 |
| Volvo Penta | KAD42A, KAD42B | 4-Stroke | 1991–2001 | 858570 |
| Volvo Penta | KAD42P-A | 4-Stroke | 1994–1997 | 858570 |
| Volvo Penta | KAMD42A, KAMD42B | 4-Stroke | 1991–1994 | 858570 |
| Volvo Penta | KAMD42P-A | 4-Stroke | 1994–1997 | 858570 |
| Volvo Penta | TAMD42B | 4-Stroke | 1993–1996 | 858570 |
| Volvo Penta | TAMD42WJ-A | 4-Stroke | 1995–2003 | 858570 |
| Volvo Penta | KAD43P-A | 4-Stroke | 1997–2005 | 858570 |
| Volvo Penta | KAMD43P-A | 4-Stroke | 1997–2005 | 858570 |
| Volvo Penta | KAD44P-A, KAD44P-B, KAD44P-C | 4-Stroke | 1998–2004 | 858570 |
| Volvo Penta | KAMD44P-A, KAMD44P-B, KAMD44P-C | 4-Stroke | 1999–2004 | 858570 |
| Volvo Penta | KAD300A | 4-Stroke | 2001–2005 | 858570 |
| Volvo Penta | KAMD300A | 4-Stroke | 2001–2004 | 858570 |
| Volvo Penta | D13 | 4-Stroke | 858570 |
Technical Specs
- Product Type
- Aftercooler/Intercooler Gasket Kit
- Installation
- Replacement service part
- Fuel Type
- Diesel
- Housing Material
- Composite/Rubber
- Dimensions
- 8.3" L x 10.1" W x 0.3" H
- Weight
- 0.08 kg (0.176 lb)
- Other Technical Attributes
- Seals aftercooler/heat exchanger connection
What’s in the Box
- 1 x Aftercooler Gasket Kit (Replaces 858570, 22109)
Installation Notes
- Ensure the engine is off and cool. Disconnect the battery and close any relevant seacocks.
- Drain the engine coolant to a level below the aftercooler assembly.
- Carefully remove any hoses, sensors, or components obstructing access to the aftercooler.
- Unbolt and remove the aftercooler housing.
- Remove the old gaskets and meticulously clean all mating surfaces of any old gasket material or debris.
- Position the new gaskets correctly on the clean surfaces, ensuring proper alignment with all bolt holes and passages.
- Reinstall the aftercooler housing and torque the bolts to the manufacturer's specified sequence and values.
- Reconnect all hoses and sensors, refill the cooling system, and reconnect the battery.
- Start the engine and carefully inspect for any coolant or air leaks around the aftercooler assembly.
Troubleshooting & FAQ
How do I find my engine model to check for compatibility?
Your Volvo Penta engine model and serial number are typically found on a metal plate or sticker affixed to the engine block, valve cover, or bell housing. Cross-reference this information with the compatibility table on this page.
What are the signs of a failing aftercooler gasket?
Common symptoms include coolant leaks around the aftercooler housing, engine overheating, white smoke from the exhaust (indicating coolant entering the combustion chamber), or a loss of boost/engine performance due to air leaks.
Do I need to use sealant with these gaskets?
Generally, these gaskets are designed to be installed dry on clean, flat surfaces. Applying sealant is not usually recommended unless explicitly specified by your engine's service manual for your particular model or to fix minor imperfections on the mating surfaces.
Is this kit suitable for the Volvo Penta D13?
While the product title mentions the D13, detailed compatibility information for this specific model is not available in our sources. We strongly recommend verifying the part number 858570 is correct for your specific D13 serial number before purchasing.
OEM vs. Aftermarket?
This listing is an aftermarket replacement (not OEM). Built to OEM-level specifications with comparable materials. Manufactured in an ISO 9002 facility, batch-inspected for consistency.
Shipping speed & cost
We ship worldwide quickly—typical transit 5–15 days. Standard shipping is free; expedited options appear at checkout where available.
Warranty & returns
Covered by a 1-year warranty against manufacturing defects under normal use. If issues arise, contact support with your order details. Returns are accepted within our standard window (unused & in original condition). See our policy page or reach out for instructions.
Safety & Important Info
- Verify images/specifications vs your original part. If anything differs—even if your model appears compatible—do not purchase.
- This is an aftermarket replacement, not an OEM component.
- Professional installation is recommended for safety and performance.
