Tension Pulley – Fits Volvo Penta KAD/KAMD Series 170–285 HP (Replaces 3582324)
Tension Pulley – Fits Volvo Penta KAD/KAMD Series 170–285 HP (Replaces 3582324) is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Worry-free returns
Worry-free returns
You may return most new, unopened items within 7 days of delivery for a full refund. We'll also pay the return shipping costs if the return is a result of our error (you received an incorrect or defective item, etc.).
You should expect to receive your refund within four weeks of giving your package to the return shipper, however, in many cases you will receive a refund more quickly. This time period includes the transit time for us to receive your return from the shipper (5 to 10 business days), the time it takes us to process your return once we receive it (3 to 5 business days), and the time it takes your bank to process our refund request (5 to 10 business days).
If you need to return an item, simply login to your account, view the order using the "Complete Orders" link under the My Account menu and click the Return Item(s) button. We'll notify you via e-mail of your refund once we've received and processed the returned item.
Delivery and Shipping
Delivery and Shipping
Free standard shipping on all orders under 1 KG
Tension Pulley – Fits Volvo Penta KAD/KAMD Series 170–285 HP (Repla...
Product Details
This is a high-quality aftermarket Tension Pulley – Fits Volvo Penta KAD Series 170–285 HP (Replaces 3582324). It is designed as a direct replacement component for Volvo Penta KAD/KAMD series diesel engines manufactured between 1993 and 2005, covering the 170–285 HP range.
This part replaces multiple OEM and aftermarket numbers, including Volvo Penta 3582324, Repower Marine RM3582324, Volvo OE VOE3582324, and MarineSpareParts AM3582324.
- Engineered for marine diesel environments.
- Adjustable with standard wrenches for correct belt tension.
- Includes one tension pulley assembly.
Part Number Matrix
Use this matrix to confirm equivalent references across OEM and aftermarket.
| Brand | Part Number |
|---|---|
| Volvo Penta | 3582324 |
| Repower Marine | RM3582324 |
| Volvo OE | VOE3582324 |
| MarineSpareParts | AM3582324 |
| Orbitrade Marine | 12324 |
Engine & Model Compatibility
Confirm your engine model/year in the table below.
This component is designed exclusively for specific Volvo Penta KAD/KAMD engines.
| Brand | Model | Rated HP | Stroke | Years | OEM Part No. |
|---|---|---|---|---|---|
| Volvo Penta | D32 | 170 HP | 4-Stroke | 1993–2005 | 3582324 |
| Volvo Penta | D42 | 230 HP | 4-Stroke | 1993–2005 | 3582324 |
| Volvo Penta | D43 | 230 HP | 4-Stroke | 1993–2005 | 3582324 |
| Volvo Penta | D44 | 260 HP | 4-Stroke | 1993–2005 | 3582324 |
| Volvo Penta | D300 | 285 HP | 4-Stroke | 1993–2005 | 3582324 |
| Volvo Penta | KAD32P-A | 170 HP | 4-Stroke | 1993–2005 | 3582324 |
| Volvo Penta | KAD42 | 230 HP | 4-Stroke | 1993–2005 | 3582324 |
| Volvo Penta | KAMD42 | 230 HP | 4-Stroke | 1993–2005 | 3582324 |
| Volvo Penta | KAD43P-A | 230 HP | 4-Stroke | 1993–2005 | 3582324 |
| Volvo Penta | KAMD43P | 230 HP | 4-Stroke | 1993–2005 | 3582324 |
| Volvo Penta | KAMD43P-A | 230 HP | 4-Stroke | 1993–2005 | 3582324 |
| Volvo Penta | KAD44P-A | 260 HP | 4-Stroke | 1993–2005 | 3582324 |
| Volvo Penta | KAD44P-B | 260 HP | 4-Stroke | 1993–2005 | 3582324 |
| Volvo Penta | KAD44P-C | 260 HP | 4-Stroke | 1993–2005 | 3582324 |
| Volvo Penta | KAMD44P-A | 260 HP | 4-Stroke | 1993–2005 | 3582324 |
| Volvo Penta | KAMD44P-C | 260 HP | 4-Stroke | 1993–2005 | 3582324 |
| Volvo Penta | KAD300-A | 285 HP | 4-Stroke | 2002–2005 | 3582324 |
| Volvo Penta | KAMD300-A | 285 HP | 4-Stroke | 2002–2005 | 3582324 |
| Volvo Penta | TAMD42WJ-A | 230 HP | 4-Stroke | 1993–2005 | 3582324 |
Technical Specs
- Product Type
- Tension/Idler Pulley
- Installation
- Wrench adjustment
- Fuel Type
- Diesel
- Connection
- Bolt mounting hole (central)
- Housing Material
- Metal with corrosion-resistant coating
- Housing Color
- Silver/Steel
- Dimensions
- 95mm diameter
- Weight
- 0.322 kg (0.71 lbs)
- Fitting Type
- Central bolt mounting
- Warranty
- 1-year against manufacturing defects
What’s in the Box
- 1 x Tension Pulley (3582324)
Installation Notes
Note: KAD series engines typically use two of these pulleys—one on the compressor and one on the water pump. This version is adjustable with spanners/wrenches.
- Turn off the engine and allow it to cool completely before starting work.
- Remove the engine cover to access the belt system.
- Release belt tension by adjusting the tensioner mechanism with a suitable wrench.
- Carefully slide the serpentine belt off the old pulley.
- Remove the central mounting bolt securing the old tensioner pulley.
- Note the orientation of the original pulley before removing it.
- Position the new tensioner pulley in the same orientation.
- Secure the new pulley using the mounting bolt, tightening to manufacturer torque specifications.
- Return the tensioner to its neutral position to re-apply tension.
- Reinstall the belt, ensuring it is properly seated on all pulleys.
- Verify belt alignment and tensioner movement before finishing.
- Replace the engine cover and test the engine.
Troubleshooting & FAQ
How many pulleys does my KAD engine need?
Volvo Penta KAD/KAMD series engines typically require two of these adjustable pulleys per engine. One is fitted to the compressor and the other to the water pump.
What are the signs of a failing tension pulley?
Common signs include a squealing or grinding noise from the engine bay, visible wobble in the pulley, uneven belt wear, or a loss of proper belt tension, which can affect the performance of the supercharger and water pump.
Can I replace just the bearing instead of the whole pulley?
This part is sold as a complete assembly. While some mechanics may press out and replace bearings, it is generally safer and more reliable to replace the entire pulley unit to ensure proper alignment and tension.
Is a special tool required for installation?
No special tools are required. This pulley is designed for adjustment and installation using standard spanners or wrenches to release tension and tighten the mounting bolt.
How often should this tensioner pulley be replaced?
There is no fixed replacement interval. It should be inspected during routine service for noise, free spin, and wobble. Replace it if you notice any signs of wear or bearing failure.
OEM vs. Aftermarket?
This listing is an aftermarket replacement (not OEM). It is built to OEM-level specifications with comparable materials and manufactured in an ISO 9002 facility, with batch inspections for consistency.
Shipping speed & cost
We ship worldwide quickly—typical transit is 5–15 days. Standard shipping is free; expedited options appear at checkout where available.
Warranty & returns
This product is covered by a 1-year warranty against manufacturing defects under normal use. If issues arise, contact support with your order details. Returns are accepted within our standard window for unused items in original condition.
Safety & Important Info
- Verify images and specifications against your original part before purchase. If anything differs—even if your model is listed as compatible—do not order.
- This is an aftermarket replacement part, not an OEM component.
- Professional installation is highly recommended for safety and optimal performance.
