Slide Hammer Puller – SEI Marine, Mercury & MerCruiser, Alpha O...
Product Details
This Slide Hammer Puller is an essential tool for various Mercury and MerCruiser applications, specifically designed for removing gimbal bearings and bearing races in Alpha One and Bravo drives, as well as on outboard lower units.
This tool is a direct aftermarket replacement for Mercury OEM part number 91-34569A1.
- Engineered to remove gimbal bearings and bearing races efficiently.
- Package includes both a 3-jaw puller and a 2-jaw adapter for versatility.
- Broad compatibility across MerCruiser sterndrives and Mercury, Yamaha, Johnson/Evinrude, and Suzuki outboards.
Part Number Matrix
Use this matrix to confirm equivalent references across OEM and aftermarket.
| Brand | Part Number | Notes |
|---|---|---|
| Mercury | 91-34569A1 | OEM cross-reference for this aftermarket puller. |
Engine & Model Compatibility
Confirm your engine model and year in the table below.
For MerCruiser models, this tool is used for gimbal bearings and bearing races on Alpha, Bravo, TR/TRS, M8, and NXT1 drives.
For Mercury outboards, this puller services lower units and is specified for a wide range of models from 2.5 HP to 250 HP.
This tool is also used to remove bearing races from the lower units of all Yamaha, Johnson/Evinrude, and Suzuki outboards.
| Brand | Model | Rated HP | Stroke | Years | OEM Part No. | Notes |
|---|---|---|---|---|---|---|
| MerCruiser | Alpha One | All | 91-34569A1 | Also used to remove bearing races. | ||
| MerCruiser | Alpha One Gen II | 1998 & Up | 91-34569A1 | |||
| MerCruiser | Bravo I | All | 91-34569A1 | Also used to remove bearing races. | ||
| MerCruiser | Bravo II | All | 91-34569A1 | Also used to remove bearing races. | ||
| MerCruiser | Bravo III | All | 91-34569A1 | Also used to remove bearing races. | ||
| MerCruiser | TR / TRS Drives | 0B721206 thru 0D805068 | 91-34569A1 | |||
| MerCruiser | M8 Drive | All | 91-34569A1 | |||
| MerCruiser | NXT1 Transom | 0M954505 & Up | 91-34569A1 | |||
| Mercury | Outboard Lower Units | All | 91-34569A1 | Also used to remove bearing races. | ||
| Mercury | 2.5 HP | 2.5 | 2-Stroke | All | 91-34569A1 | Non-shift models |
| Mercury | 3.3 HP | 3.3 | 2-Stroke | All | 91-34569A1 | |
| Mercury | 6 HP | 6 | 2-Stroke | All | 91-34569A1 | |
| Mercury | 8 HP | 8 | 2-Stroke | All | 91-34569A1 | |
| Mercury | 9.9 HP | 9.9 | 2-Stroke | 1998 | 91-34569A1 | |
| Mercury | 15 HP | 15 | 2-Stroke | 1998 | 91-34569A1 | |
| Mercury | 20 HP | 20 | 2-Stroke | All | 91-34569A1 | 2 Cyl. |
| Mercury | 25 HP | 25 | 2-Stroke | 1996–1998 | 91-34569A1 | 2-Cylinder |
| Mercury | 30 Jet | 30 | 2-Stroke | All | 91-34569A1 | 3 Cyl. |
| Mercury | 40 HP | 40 | 2-Stroke | 1995–1997 | 91-34569A1 | 3 Cyl. |
| Mercury | 40 Jet | 40 | All | 91-34569A1 | ||
| Mercury | 45 Jet | 45 | All | 91-34569A1 | ||
| Mercury | 50 HP | 50 | 2-Stroke | All | 91-34569A1 | 3 Cyl. |
| Mercury | 55 HP | 55 | 2-Stroke | All | 91-34569A1 | 3 Cyl. |
| Mercury | 60 HP BigFoot | 60 | 3-Cylinder | All | 91-34569A1 | |
| Mercury | 65 Jet | 65 | 3-Cylinder | All | 91-34569A1 | |
| Mercury | 75 HP | 75 | 3-Cylinder | All | 91-34569A1 | |
| Mercury | 90 HP | 90 | 3-Cylinder | All | 91-34569A1 | |
| Mercury | 100 HP | 100 | 4-Cylinder | All | 91-34569A1 | |
| Mercury | 105 Jet | 105 | All | 91-34569A1 | ||
| Mercury | 110 Jet | 110 | 2.5L | All | 91-34569A1 | |
| Mercury | 115 HP | 115 | 4-Cylinder | All | 91-34569A1 | |
| Mercury | 125 HP | 125 | 4-Cylinder | All | 91-34569A1 | |
| Mercury | 135 HP | 135 | 2.5L | All | 91-34569A1 | CARB & EFI/DFI models |
| Mercury | 140 Jet | 140 | 2.5L | All | 91-34569A1 | CARB models |
| Mercury | 150 HP | 150 | 2.5L | All | 91-34569A1 | CARB & EFI/DFI models |
| Mercury | 175 HP | 175 | 2.5L | All | 91-34569A1 | CARB & EFI/DFI models |
| Mercury | 200 HP | 200 | 2.5L & 3.0L | All | 91-34569A1 | CARB, EFI & DFI models |
| Mercury | 225 HP | 225 | 3.0L | All | 91-34569A1 | CARB, EFI & DFI models |
| Mercury | 240 EFI Jet Drive | 240 | All | 91-34569A1 | ||
| Mercury | 250 HP | 250 | 3.0L | All | 91-34569A1 | EFI & DFI models |
| Yamaha | Outboards | All | Also used to remove bearing races from lower units. | |||
| Johnson/Evinrude | Outboards | All | Also used to remove bearing races from lower units. | |||
| Suzuki | Outboards | All | Also used to remove bearing races from lower units. |
Technical Specs
- Product Type
- Slide Hammer Puller
- Application
- Used to remove gimbal bearings and bearing races in Alpha One and Bravo Drives, and outboard lower units.
- Weight
- 3.17 kg (7.00 lb)
- Dimensions (L x W x H)
- 62.5 cm x 13.0 cm x 9.5 cm
- Included Attachments
- Comes with a 3-jaw puller and a 2-jaw adapter.
- Technical Note
- May require material removal from the bottom of the puller jaw to fit behind some bearing races.
What’s in the Box
- 1 x Slide Hammer Assembly with 3-Jaw Puller (Replaces 91-34569A1)
- 1 x 2-Jaw Adapter
Installation Notes
- Ensure the engine is off and the drive or lower unit is safely secured and supported.
- Select the appropriate jaw adapter (2-jaw or 3-jaw) for the component being removed.
- Securely attach the jaws behind the bearing or race, ensuring a firm grip.
- Thread the slide hammer shaft into the puller attachment.
- Use firm, controlled outward sliding motions to extract the component. Repeat as necessary.
- Note: For certain bearing races, minor material removal (grinding) from the jaw's edge may be needed for a proper fit.
- After removal, inspect the housing for wear or damage before installing the new part.
- Professional installation is highly recommended for safety and to prevent component damage.
Troubleshooting & FAQ
What is this tool specifically used for?
This is a professional-grade slide hammer puller designed to extract gimbal bearings and bearing races from various sterndrives and outboard lower units, primarily for MerCruiser Alpha/Bravo drives and Mercury outboards.
How can I confirm this tool will fit my engine?
It is designed for a broad range of MerCruiser drives and outboards from Mercury, Yamaha, Suzuki, and Johnson/Evinrude. Please review the detailed "Engine & Model Compatibility" table on this page to verify your specific model and year.
Is this a genuine Mercury tool?
No, this is an aftermarket tool built to the same specifications as Mercury OEM part 91-34569A1. It offers comparable performance and durability at a better value.
The puller jaw doesn't fit behind the bearing race. What's wrong?
This is a common situation with some applications. As noted in the specifications, you may need to perform a minor modification by grinding a small amount of material from the bottom of the puller jaws to allow it to slip behind certain races.
When should I use the 2-jaw versus the 3-jaw adapter?
The 3-jaw puller provides a stable, evenly distributed pulling force and is ideal for most gimbal bearings. The 2-jaw adapter is intended for situations with limited clearance or for gripping bearing races where a 3-jaw puller will not fit.
OEM vs. Aftermarket?
This listing is an aftermarket replacement (not OEM). Built to OEM-level specifications with comparable materials. Manufactured in an ISO 9002 facility, batch-inspected for consistency.
