Outboard Propeller Drive Pin – Fits Johnson/Evinrude 10–25 HP (Replaces 307949, 765545)

$3.66

Shipping calculated at checkout.

Outboard Propeller Drive Pin – Fits Johnson/Evinrude 10–25 HP (Replaces 307949, 765545) is backordered and will ship as soon as it is back in stock.

Worry-free returns

You may return most new, unopened items within 7 days of delivery for a full refund. We'll also pay the return shipping costs if the return is a result of our error (you received an incorrect or defective item, etc.).

You should expect to receive your refund within four weeks of giving your package to the return shipper, however, in many cases you will receive a refund more quickly. This time period includes the transit time for us to receive your return from the shipper (5 to 10 business days), the time it takes us to process your return once we receive it (3 to 5 business days), and the time it takes your bank to process our refund request (5 to 10 business days).

If you need to return an item, simply login to your account, view the order using the "Complete Orders" link under the My Account menu and click the Return Item(s) button. We'll notify you via e-mail of your refund once we've received and processed the returned item.

Delivery and Shipping

Free standard shipping on all orders under 1 KG

If you have any questions, feel free to email us at info@sierramarines.com, and we’ll get back to you within 20–36 hours.

Product Details

This Outboard Propeller Drive Pin is designed for specific Johnson and Evinrude 2-stroke outboard engines, primarily 10 HP, 18 HP, 20 HP, and 25 HP models manufactured between 1968 and 1979. It is intended for non-thru hub exhaust and pin drive propeller applications.

Serves as a direct replacement for Johnson/Evinrude OEM part numbers 307949 and 765545, as well as multiple aftermarket equivalents including QUICKMARINE 307949, UanofCn 307949, and others.

Installs via a simple press-fit into the propeller hub.
Made from corrosion-resistant metal for durability in marine environments.
Engineered as a sacrificial component to protect the engine's gearcase and drivetrain from damage upon impact.

Part Number Matrix

Use this matrix to confirm equivalent references across OEM and aftermarket.

Brand	Part Number
Johnson/Evinrude	307949
Johnson/Evinrude	765545
QUICKMARINE	307949
UanofCn	307949
FUSCH	307949
Vudajuley	307949
Ciuouient	307949
EVRBUL	307949

Engine & Model Compatibility

Confirm your engine model/year in the table below.

For Johnson/Evinrude models, this part fits a wide range of vintage and later model 2-stroke outboards, particularly those with non-thru hub exhaust and pin-driven propellers.

Brand	Model	Rated HP	Stroke	Years	OEM Part No.	Notes
Johnson/Evinrude	Various	10	2-Stroke	1968–1979	307949, 765545	Early propeller models
Johnson/Evinrude	Various	18	2-Stroke	1968–1979	307949, 765545	Early propeller models
Johnson/Evinrude	Various	20	2-Stroke	1968–1979	307949, 765545	Early propeller models
Johnson/Evinrude	Various	25	2-Stroke	1968–1979	307949, 765545	Early propeller models
Johnson/Evinrude	Various	6	2-Stroke	1980–1983	307949	Non-thru hub exhaust and pin drive
Johnson/Evinrude	Various	9.5	2-Stroke	1964–1973	307949	Non-thru hub exhaust and pin drive
Johnson/Evinrude	European Models	10, 12, 14	2-Stroke	1982–1994	307949	European market models
Johnson/Evinrude	Various	8-15	2-Stroke	2000+	307949	Non-thru hub exhaust and pin drive

Technical Specs

Product Type: Propeller Drive Pin / Shear Pin
Installation: Press-fit into propeller
Housing Material: Metal
Housing Color: Silver/Metal
Dimensions: 3.5 cm diameter (estimated from product listing)
Fitting Type: Drive/Shear Pin
Other Technical Attributes: Designed as sacrificial failure point to protect gearcase and drivetrain

What’s in the Box

1 x Propeller Drive Pin (307949/765545)

Installation Notes

Ensure the engine is off and the ignition key is removed. Shift the outboard into the neutral position.
Remove the cotter pin, propeller nut, and any washers from the propeller shaft.
Slide the old propeller off the shaft. If the old drive pin is sheared, remove both pieces from the shaft and the propeller hub.
Align the new propeller on the shaft, ensuring the drive pin hole lines up with the hole in the propeller shaft.
Insert the new drive pin through the propeller hub and the propeller shaft until it is centered.
Reinstall any washers and the propeller nut. Tighten the nut to the manufacturer's specified torque.
Secure the nut by inserting a new cotter pin and bending its ends around the castellated nut.

Troubleshooting & FAQ

What is the purpose of a propeller drive pin?

A propeller drive pin (or shear pin) is a sacrificial part designed to break if the propeller strikes an underwater object. This protects the more expensive and critical drivetrain components, like the gearcase, from catastrophic damage.

How do I know if my drive pin needs replacement?

If your engine revs up but the boat doesn't move or moves very slowly, the drive pin has likely sheared. You can confirm by removing the propeller and visually inspecting the pin. Always carry spares on board.

Will this fit my Johnson 15 HP from 1995?

Yes, based on the compatibility data, this pin fits Johnson/Evinrude models in the 8-15 HP range from 2000 and newer, as well as many earlier models. Always verify that your engine uses a non-thru hub exhaust and pin drive system before ordering.

Is this pin reusable?

No. Once a drive pin shears, it is destroyed and must be replaced with a new one. They are not designed to be repaired or reused.

OEM vs. Aftermarket?

This listing is an aftermarket replacement (not OEM). Built to OEM-level specifications with comparable materials. Manufactured in an ISO 9002 facility, batch-inspected for consistency.

Shipping speed & cost?

We ship worldwide quickly—typical transit 5–15 days. Standard shipping is free; expedited options appear at checkout where available.

Warranty & returns?

Covered by a 1-year warranty against manufacturing defects under normal use. If issues arise, contact support with your order details. Returns are accepted within our standard window (unused & in original condition). See our policy page or reach out for instructions.

Safety & Important Info

Verify images/specifications vs your original part. If anything differs—even if your model appears compatible—do not purchase.
This is an aftermarket replacement, not an OEM component.
Professional installation is recommended for safety and performance.
