Product Details
This aftermarket Crankshaft Assembly is designed as a direct factory replacement for Yamaha 9.9HP, 13.5HP, and 15HP 2-stroke outboard engines manufactured between 1984 and 1996. It ensures reliable performance for models including F, FM, FEM, MHV, FMH, MSH, FW, and MHH series.
It serves as a direct interchange for Yamaha OEM part numbers 63V-11400-01-00 (complete assembly) and 63V-11432-00-00 (Crank 3 component), as well as the Parsun T15-04020104 equivalent.
- Installation: Designed for a direct fit, replacing the original factory part.
- Material: Constructed from durable steel with a polished surface treatment for longevity.
- Engine Type: Compatible with 2-stroke gasoline outboard engines.
Part Number Matrix
Use this matrix to confirm equivalent references across OEM and aftermarket.
| Brand | Part Number | Notes |
|---|---|---|
| Yamaha | 63V-11400-01-00 | Complete Assembly |
| Yamaha | 63V-11432-00-00 | Crank 3 Component |
| Parsun | T15-04020104 | Aftermarket equivalent |
Engine & Model Compatibility
Confirm your engine model/year in the table below.
For Yamaha owners, this part fits a wide range of 9.9HP, 13.5HP, and 15HP 2-stroke models from the mid-1980s to mid-1990s.
| Brand | Model | Rated HP | Stroke | Years | OEM Part No. |
|---|---|---|---|---|---|
| Yamaha | 9.9F | 9.9 | 2-Stroke | 1984–1996 | 63V-11432-00-00 |
| Yamaha | 9.9FM | 9.9 | 2-Stroke | 1984–1996 | 63V-11432-00-00 |
| Yamaha | 9.9FEM | 9.9 | 2-Stroke | 1984–1996 | 63V-11432-00-00 |
| Yamaha | 9.9MHV | 9.9 | 2-Stroke | 1984–1996 | 63V-11432-00-00 |
| Yamaha | 9.9FMH | 9.9 | 2-Stroke | 1984–1996 | 63V-11432-00-00 |
| Yamaha | 9.9MSH | 9.9 | 2-Stroke | 1984–1996 | 63V-11432-00-00 |
| Yamaha | 13.5AMH | 13.5 | 2-Stroke | 1984–1996 | 63V-11432-00-00 |
| Yamaha | 15F | 15 | 2-Stroke | 1984–1996 | 63V-11432-00-00 |
| Yamaha | 15FEM | 15 | 2-Stroke | 1984–1996 | 63V-11432-00-00 |
| Yamaha | 15FM | 15 | 2-Stroke | 1984–1996 | 63V-11432-00-00 |
| Yamaha | 15MH | 15 | 2-Stroke | 1984–1996 | 63V-11432-00-00 |
| Yamaha | 15MSH | 15 | 2-Stroke | 1984–1996 | 63V-11432-00-00 |
| Yamaha | 15FW | 15 | 2-Stroke | 1984–1996 | 63V-11432-00-00 |
| Yamaha | 15MHH | 15 | 2-Stroke | 1984–1996 | 63V-11432-00-00 |
| Parsun | T15 | 15 | 2-Stroke | T15-04020104 |
Technical Specs
- Product Type
- Crankshaft Assembly / Crank 3 Component
- Installation
- OEM Factory Replacement
- Fuel Type
- Gasoline
- Housing Material
- Steel
- Surface Treatment
- Polished
- Weight
- ~25 lbs (11.3 kg) for complete assembly
- Product Dimensions
- 8.5" L x 10.0" W x 4.0" H
- Box Dimensions
- 8.5" L x 10.0" W x 4.0" H
- Warranty
- 1 Year
What’s in the Box
Your package contents will vary depending on your selection:
If purchasing the complete crankshaft assembly (replaces 63V-11400-01-00):
- 1 x Complete Crankshaft Assembly, which includes:
- 1 x Crank 1 (63V-11412-00-00)
- 1 x Crank 2 (63V-11422-00-00)
- 1 x Crank 3 (63V-11432-00-00)
- 1 x Crank 4 (63V-11442-00-00)
If purchasing the Crank 3 component only (replaces 63V-11432-00-00):
- 1 x Crank 3 Component (63V-11432-00-00)
Installation Notes
- Disconnect the battery and ensure the engine is off and cool.
- Remove the engine cover and flywheel to access internal components.
- Carefully disassemble the powerhead, labeling all parts and connections for reassembly.
- Remove the old crankshaft assembly, taking note of bearing and seal positions.
- Clean all mating surfaces of old gasket material and grime.
- Install the new crankshaft assembly, ensuring all bearings and seals are correctly seated.
- Reassemble the powerhead according to the manufacturer's service manual, using new gaskets.
- Torque all bolts to the specified values in the correct sequence.
- Reinstall the flywheel and all other external components.
- Reconnect the battery, start the engine, and check for proper operation and any leaks.
Troubleshooting & FAQ
How do I know if my crankshaft is failing?
Common signs of a bad crankshaft include excessive engine vibration, knocking or rumbling sounds from the lower engine block, or a complete engine seizure. Visible damage or cracks on the old crankshaft during an inspection also indicate a need for replacement.
Is this the complete assembly or just one part?
This listing may be for the complete crankshaft assembly (63V-11400-01-00) or for the individual 'Crank 3' component (63V-11432-00-00). Please check the "What's in the Box" section and your order selection to confirm what is included.
Will this fit a 4-stroke Yamaha engine?
No, this crankshaft is specifically designed for 2-stroke Yamaha outboard engines. It is not compatible with any 4-stroke models.
Do I need special tools for this installation?
Yes, replacing a crankshaft is a complex job that requires specialized tools such as a flywheel puller, torque wrench, and potentially a press for bearings. Access to a full service manual for your specific engine model is essential. Professional installation is highly recommended.
What is the difference between the complete assembly and the Crank 3 component?
The complete assembly (63V-11400-01-00) includes all four 'Crank' components that make up the entire crankshaft. The Crank 3 component (63V-11432-00-00) is just one of those four pieces. You should only purchase the individual component if you have specifically diagnosed a failure in that part alone.
What is the recommended maintenance for a new crankshaft?
After installation, follow your engine's standard break-in procedure. Ensure you use the correct 2-stroke oil-to-fuel ratio at all times. Regular maintenance, including checking for fuel and air leaks, will ensure a long service life.
OEM vs. Aftermarket?
This listing is an aftermarket replacement (not OEM). Built to OEM-level specifications with comparable materials. Manufactured in an ISO 9002 facility, batch-inspected for consistency.
Shipping speed & cost
We ship worldwide quickly—typical transit 5–15 days. Standard shipping is free; expedited options appear at checkout where available.
Warranty & returns
Covered by a 1-year warranty against manufacturing defects under normal use. If issues arise, contact support with your order details. Returns are accepted within our standard window (unused & in original condition). See our policy page or reach out for instructions.
Safety & Important Info
- Verify images/specifications vs your original part. If anything differs—even if your model appears compatible—do not purchase.
- This is an aftermarket replacement, not an OEM component.
- Professional installation is recommended for safety and performance.
